SM-Encoder Output Plus - Interface module - CONTROL TECHNIQUES
This SM-Encoder Output Plus interface module from Control Techniques is a programming console from the UNIDRIVE range.
Module compatible with Unidrive SP, Quantum MP, Digitax ST, Mentor MP drives.
This SM-Encoder Output Plus Control techniques interface module is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
Control Techniques’ incremental encoder input and output option module to enable connection with external motion controllers.
Supports the following encoder inputs:
-Closed loop vector motor feedback
-Quadrature encoder input
-Marker pulse
-Incremental encoders with frequency and direction signals
-Incremental encoders with forward and reverse signals
-Maximum input frequency 500kHz
-5V, 8V and 15V signals
Simulated encoder output types included are:
-Quadrature
-Frequency and direction
-Forward and reverse
-Marker lock
Features
The SM-Encoder Plus and SM-Encoder Output Plus Solutions Modules provide an interface for an additional encoder to be connected to the drive, to be used as position and speed feedback for the drive. Typical uses for these Solutions Modules would be to input a speed/position reference from a line speed encoder, or to digitally lock the drive to a master reference using the position controller in drive menu 13. The SM-Encoder Output Plus has all the features of the SM-Encoder Plus module but also provides an encoder power supply output and simulated encoder outputs.
Control Techniques is a leading manufacturer of AC and DC speed variation, servo motors and power conversion technologies for commercial and industrial applications. Their innovative products are used in the most demanding applications, requiring performance, reliability and energy efficiency.
Nidec Control Techniques has been at the forefront of industrial-driven drive technology for more than 40 years. They are dedicated to the advancement of automation. From product development to their headquarters to their 45 automation centers around the world, Nidec Control Techniques provides industry-relevant solutions. They guarantee high performance, reliability and energy efficiency in all applications.
