UD75 - CTNet Interface Card - LEROY SOMER
UD75
This LEROY SOMER UD75 reference interface board is part of the UNIDRIVE range.
May be marketed under the brand name CONTROL TECHNIQUES or EMERSON.
This interface card LEROY SOMER UD75 is available to you in standard supply or exchange to replace your defective equipment and has a warranty.
Standard Exchange Service
Reconditioned and tested systems
From 6 to 12
month warranty
Standard Exchange Service
New systems
From 12 to 24
month warranty
Supply Service
Reconditioned and tested systems
From 6 to 12
month warranty
Supply Service
New systems
From 12 to 24
month warranty
Supply Service
Sold for parts – no warranty
Repair service
Repair will be made to damaged and defectiv units
From 3 to 18
month warranty
Fast
delivery
guaranteed
products
Secure
payment
The UD75 CTNet Interface card for Unidrive is supplied in a large option module. It is an add-on card for the UD70 Applications card. The UD70 processor and operating system handles all network activity, and uses a Dual-Port RAM interface to transfer data between itself and the drive.
The UD70 retains full functionality, allowing the user to download normal DPL application programs. No program modifications are required to allow existing DPL programs to run. A different UD70 operating system file (“UD70NET.SYS”) is used, and the UD70 has this system file pre-loaded.
1. Isolate the drive from the mains supply and allow 5 minutes for the DC Bus capacitors to discharge.
2. Insert Large Option Module as shown below. Ensure that it is correctly inserted. The module will click firmly into place.
3. To remove the module, pull on the black tab, and the module will disengage from the connector and pull out of the drive.
The MD29AN CTNet Interface card for Mentor II is single add-on card. It fits onto the 40 pin header on the MDA-2B card on the Mentor II itself.
The MD29AN processor and operating system handles all network activity, and uses a Dual-Port RAM interface to transfer data between itself and the drive.
The MD29AN retains full functionality, allowing the user to download normal DPL application programs. No program modifications are required to allow existing DPL programs to run. A different MD29 operating system file (“M2NET.SYS”) is used, and the MD29AN has this system file pre-loaded.
- Height
- 5 cm / 1,9 in
- Width
- 14 cm / 5,5 in
- Length
- 7 cm / 2,7 in
- Weight
- 0,1 kg / 0,2 lb
- Family
- UNIDRIVE
- Reference
- UD75
Refurbished
3002173456407
300875623381
LEROY SOMER, leader and global specialist in industrial alternators and drive systems, designs and industrializes the most innovative eco-technology solutions to serve the industrial and tertiary markets.
Founded in 1919 by Marcellin Leroy
International company headquartered in Angoulême in Charente (France), worldwide specialist in alternators and electromechanical and electronic drive systems. Subsidiary of the American group Emerson since 1990.
In 2017, Nidec Cormoration took effective control of Leroy Somer.
