SM-Resolver - Interface module - CONTROL TECHNIQUES
This SM-Resolver interface module from Control Techniques is a programming console from the UNIDRIVE range.
Module compatible with Unidrive SP, Quantum MP, Digitax ST, Mentor MP drives.
This SM-Resolver Control techniques interface module is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
SM-Resolver
The SM-Resolver module allows the drive to exploit the signal from a resolver, used as position or speed feedback, and to simulate an incremental encoder signal in quadrature (image of the main encoder of the drive or of the encoder connected on the SM-Resolver option).
Note: The SM-resolver module cannot be used in Open Loop.
The SM-Resolver provides an interface for a resolver to be connected to the Unidrive SP, to be used as position and speed feedback for the drive. The SM Resolver also provides a simulated quadrature encoder output.
The SM-Resolver will only provide speed and position feedback when selected as the speed/position feedback source for the drive. Therefore, the SM-Resolver does not work when the drive is running in open loop mode. Similarly, it is not possible to use a resolver as a speed/position reference.
All three Solutions Module slots can accommodate an SM-Resolver simultaneously, however, only one of the three can be used to provide velocity/position feedback at any time. given time (see NOTE above)
Dimensions
The SM-Resolver module can be integrated into the entire UNIDRIVE SP range and therefore does not change the size of the drive.
