7CX408.50-1

This B&R I/O module bears the reference 7CX408.50-1. It corresponds to the Compact I/O range.

CAN communication, 16 Inputs, 16 Outputs.

B&R compact module reconditioned and tested on a manufacturer's test bench (100% test).

In stock, ready to ship.
State
  • Refurbished Supply
Warranty
€750.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



General informations

Connecting Devices Remotely

Space-saving Compact I/O system modules reduce the wiring of sensors and actuators. Discrete I/O signals are aggregated on the modules and transferred to the controller via a link fieldbus. The system is ideally suited for use in standard IP20 operating environments.

Flexibility for sensors and actuators

The modules of the compact I/O system already include signal adaptation for various purposes. in addition to the classic digital signals, there are also modules able to manage the evaluation of rotary encoders, gate measurement, event counters or pulse width signals. The analog modules are also supplemented with temperature inputs, strain gauge evaluation or resistance measurement. The compact I/O system always provides the right combination of I/O for each application.

Communications

The modules of the Compact I/O system are equipped with CAN I/O or X2X Link interfaces. All I/O signals are bundled together and sent to the higher level controller through this channel. This extends the backplane I/O into the field. The Compact I/O system can be combined with all B&R controller families and other optional components. This allows a custom and cost effective automation architecture to be created for each application.

I/O modules for distributed applications

IP20 compact I/O modules offer exceptional solutions when it comes to applications that handle remote I/O signals, ranging from simple digital inputs to SSI encoders. In addition to being able to mount this system directly on the machine or on a mounting rail, its optimum performance and compact size of 170 x 80 x 30 mm (H x W x D) translates into almost limitless possibilities.

Height
4,5 cm / 1,7 in
Width
8 cm / 3,1 in
Length
17 cm / 6,6 in
Weight
0,4 kg / 0,8 lb
Family
Compact I/O - B&R
Reference
7CX408.50-1
Refurbished

B&R is an Austrian company founded in 1979 by Erwin Bernecker and Josef Rainer in Eggelsberg near Salzburg.

B&R provides complete solutions in industrial automation.

Range of extended products programmed and configured using Automation Studio software.
