SM-I/O 24V Protected - Interface module - CONTROL TECHNIQUES

Features

The SM-I/O 24V Protected is designed as an overvoltage protected I/O solution Module.

The Solutions Module is capable of withstanding an input voltage of +48V applied to the +24V Digital I/O Terminals.

The SM-I/O 24V Protected can be used on the following products:

• Unidrive SP

• SK Commander

• Commander GP20

The SM-I/O 24V Protected increases the I/O capability of the drive by adding the following to the existing I/O:

• 2 analog current outputs

• 4 digital inputs/outputs*

• 3 digital inputs

• 2 x relays (nominal contact 30 Vdc)**

All connections between the Solutions Module and the drive are made through the drive connector. Connections from external equipment to the relay, digital I/O and analog outputs are made via a 17-way removable screw connector. On Unidrive SP, a total of three SM-I/O 24V Protected modules can be fitted at any one time. On the Commander SK only one can be mounted, on the Commander GP20 two can be mounted.

*Only three digital outputs are available with the Commander SK.

**1 relay on Commander SK

The SM-I/O 24V Protected can be identified by:

1. The label located under the Solutions module.

2. The color coding on the front of the Solutions Module, with the SM-I/O 24V Protected being cobalt blue.
