MHDS1017N00 - Motion servo drive - SCHNEIDER ELECTRIC
This servo drive for motion control SCHNEIDER ELECTRIC reference MHDS1017N00 is an AC servo drive for universal control. LEXIUM 17S Series
LEXIUM 17S servo drive: 3x-230-480V, 50 / 60Hz. Three phase: 16.8A
This servo drive MHDS1017N00 is at your disposal to replace your defective equipment and has a guarantee adapted to your needs
- use an insulation star transformer in order to re-create a local TT or TN system.
This way allows the rest of the wiring to stay an IT system (only warning in case of the first fault.)
- use a special Residual Current Circuit Breaker (RCCB) that is able to work with dc and high peak currents. This device detects unbalance of phases with regard to earth.
Warning: When the first fault occurs, the RCCB has to switch off quickly power of the drives. Set of the residual current value must be carefully done and must be started with the lowest available value (for example: 30mA.)
- Vigirex, model RH328AF (Reference: 50055)
- One of these magnetic cores:
. model TA, 30mm in internal diameter (Reference: 50437)
. model PA, 50mm in internal diameter (Reference: 50438)
. model IA, 80mm in internal diameter (Reference: 50439)
SCHNEIDER ELECTRIC is a French industrial group with international dimension, which manufactures and offers electricity management products, automation and solutions adapted to these trades.
Having consolidated its financial base thanks to the arrival of new shareholders and the simplification of its structures, Schneider began its redeployment at the end of the 1980s. Having joined Merin Gerin in the group (1986), the general management embarked on a acquisition strategy, marked by the integration of important companies that will become the core of the current group:
Télémécanique (1988)
Square D (1991)
Merlin Gerin (1992)
Modicon (1996)
