MHDS1028N00

This servo drive for motion control SCHNEIDER ELECTRIC reference MHDS1028N00 is an AC servo drive for universal control. LEXIUM 17S Series

LEXIUM 17S servo drive: 3x-230-480V, 50 / 60Hz. Three phase: 28A

This servo drive MHDS1028N00 is at your disposal to replace your defective equipment and has a guarantee adapted to your needs

In stock, ready to ship.
State
  • Refurbished Supply
Warranty
€1,210.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment


Each member of the Lexium 17S series SERCOS drive family is comprised of a three-phase brushless servo amplifier, power supply, high-performance digital controller and SERCOS fiber optic interface all housed in a single enclosure.
The Lexium 17S family of servo amplifiers is to be used on earthed three-phaseindustrial mains supply networks (TN-system, TT-system with earthed neutral point, not more than 5000 rms symmetrical amperes).
The Lexium drives are incompatible with the IT system because interference suppression filters are internal and connected to earth. If the user wants to connect Lexium drives to an IT system, he may:
- use an insulation star transformer in order to re-create a local TT or TN system.
This way allows the rest of the wiring to stay an IT system (only warning in case of the first fault.)
- use a special Residual Current Circuit Breaker (RCCB) that is able to work with dc and high peak currents. This device detects unbalance of phases with regard to earth.
Warning: When the first fault occurs, the RCCB has to switch off quickly power of the drives. Set of the residual current value must be carefully done and must be started with the lowest available value (for example: 30mA.)
Following equipment of Merlin Gerin can be used :
- Vigirex, model RH328AF (Reference: 50055)
- One of these magnetic cores:
. model TA, 30mm in internal diameter (Reference: 50437)
. model PA, 50mm in internal diameter (Reference: 50438)
. model IA, 80mm in internal diameter (Reference: 50439)
If the servo amplifiers are used in residential areas, or in business or commercial premises, then additional filter measures must be implemented by the user.
The Lexium 17S family of servo amplifiers is only intended to drive specific brushless synchronous servomotors from the Lexium BPH series, with closed-loop control of torque, speed and/or position. The dielectric withstand voltage of the motors must be at least as hight as the DC-link voltage of the servo amplifier.
Use only copper wire. Wire size may be determinated from EN 60204 (or table 310- 16 of the NEC 60°C or 75°C column for AWG size).
Height
32,5 cm / 12,7 in
Width
7 cm / 2,7 in
Length
26,5 cm / 10,4 in
Weight
2,5 kg / 5,5 lbs
Family
LEXIUM 17S
Reference
MHDS1017N00
Refurbished
3004566617839
300177665737

SCHNEIDER ELECTRIC is a French industrial group with international dimension, which manufactures and offers electricity management products, automation and solutions adapted to these trades.

Having consolidated its financial base thanks to the arrival of new shareholders and the simplification of its structures, Schneider began its redeployment at the end of the 1980s. Having joined Merin Gerin in the group (1986), the general management embarked on a acquisition strategy, marked by the integration of important companies that will become the core of the current group:

Télémécanique (1988)

Square D (1991)

Merlin Gerin (1992)

Modicon (1996)
