Schneider Electric frequency drive ATV61HD22M3X – ALTIVAR 61

The frequency drive ATV61HD22M3X is part of the Altivar 61 series from SCHNEIDER ELECTRIC, a range known for controlling three-phase asynchronous motors on 200-240 V networks. Designed for ventilation, pumping and conveying applications, this 22 kW, 30 CV model delivers precise speed control across a wide operating range. It meets the needs of maintenance teams and integrators looking for a ready-to-use reference to upgrade an existing installation or replace an in-service drive. Its IP20 enclosure, EMC filter-free version and included control terminal facilitate integration into an electrical cabinet with local setup. The mains frequency range of 47.5 to 63 Hz and typical switching frequency of 12 kHz help adapt to the electrical environment and the motor's acoustic requirements. Manufacturer documentation, available as installation and programming guides, supports methodical commissioning and the securing of motor protection settings and acceleration ramps.

Technical specifications

• Manufacturer reference: ATV61HD22M3X
• Range: Altivar 61
• Manufacturer: Schneider Electric
• Type: Variable speed drive for three-phase asynchronous motor
• Supply voltage: 200-240 V three-phase, 47.5...63 Hz
• Rated power: 22 kW, 30 CV
• Typical output current: 88 A at 12 kHz, 230 V, 3 phases
• Output frequency range: 0.1 to 599 Hz
• Speed range: ratio 1:100 in open-loop
• Ingress protection: IP20, EMC filter-free version
• Local interface: control terminal
• Dimensions: 240 x 420 x 236 mm
• Weight: 30 kg
• Documentation: installation and programming guides available

Overview of the Altivar 61 range

The Altivar 61 series is aimed at applications where precise speed control and energy optimisation are priorities. Deployed in industrial utilities and HVAC, it is valued for service continuity and clear parameterisation. Drives in this range allow fine adaptation to typical fluid load profiles, with ramp functions, current limiting and configurable protections via the terminal. The standard configuration for reference ATV61HD22M3X integrates easily into a cabinet on a 200-240 V three-phase network, with an extended frequency range to cover a wide spectrum of applications.

• Fluid and HVAC applications: flow and pressure control for pumps and fans, improving energy efficiency by adjusting speed.
• Industrial utilities and continuous processes: managing conveyors and drives requiring stable speed and controlled restarts.

The ATV61HD22M3X targets three-phase asynchronous motors 200-240 V with a rated power of 22 kW. Its IP20 enclosure and EMC filter-free configuration suit installations with external filtering or EMC measures handled at cabinet level. The output frequency range of 0.1 to 599 Hz and the 1:100 open-loop speed ratio provide precise control to match motor behaviour to process requirements.

Industrial applications

The Altivar 61 ATV61HD22M3X drive covers a wide range of uses in industrial and technical tertiary environments. Speed regulation helps stabilise process variables, reduce mechanical stress and optimise electrical consumption.

• Centrifugal and positive displacement pumps: flow and pressure control in chilled water networks, process circuits and pumping stations.
• Ventilation and air handling: control of fans, AHUs and extractors with fine speed adjustment for comfort and energy performance.
• Conveying and continuous handling: driving belts, rollers and screw conveyors, smooth starts and repeatable stops.
• Light compression and workshop auxiliaries: maintaining stable speed to improve utility availability.
• Water treatment and site utilities: adapting speed to level, flow or pressure setpoints.

Integration and communication

The ATV61HD22M3X provides a control terminal and a local terminal for on-site configuration. Configuration functions, including ramps, current limits and motor protections, are accessible via menu navigation. The Altivar 61 family supports fieldbus connections via optional cards depending on version and setup. Integration into a programmable logic controller architecture is done either via digital and analogue I/Os or via communication, consistent with plant architecture. For advanced control functions, detailed configuration is documented in the Schneider Electric programming guides available for this series.

On the electrical side, the 200-240 V three-phase input voltage, mains frequency 47.5...63 Hz and typical switching frequency 12 kHz facilitate adaptation to the motor and acoustic context. The EMC filter-free version means an upstream filter may be required depending on the environment. Special attention should be paid to sizing protections, thermal dissipation in the cabinet and clearance requirements to ensure load endurance and equipment lifetime.

Availability and warranty

The frequency drive ATV61HD22M3X is offered by Standard Exchange Industry as reconditioned supply, as a standard exchange or as a repair, bench-tested and delivered with warranty according to the selected service. Shipping is arranged within 24 to 72 hours to over 120 countries, with technical assistance for reference identification and compatibility with your 200-240 V asynchronous motor. In line-stop or upgrade situations, our team will support you to secure the replacement, prepare commissioning and plan, if necessary, EMC compliance and protection accessories. With installation and programming documentation available, you have what you need to set the 0.1 to 599 Hz frequency range, adjust ramps, and verify the typical operating current of 88 A at 12 kHz on 230 V, 3 phases. This approach aims for a rapid production restart with proven equipment from the Altivar 61 range by SCHNEIDER ELECTRIC.
