ATV61HD11M3X - Speed drive - SCHNEIDER ELECTRIC

Schneider Electric frequency drive ATV61HD11M3X - ALTIVAR 61

The frequency drive ATV61HD11M3X belongs to the Altivar 61 series by SCHNEIDER ELECTRIC. Designed for speed control of three-phase asynchronous motors, it meets the demands of industrial process environments where uptime, energy optimisation and reliability are critical. With a rated power of 11 kW (15 HP), a 240 V three-phase supply and an IP20 rating, this model is panel-mounted and targets production lines, utilities and technical tertiary installations. The V/f control in 2 or 5 points features automatic load adaptation, adjustable parameters and the option to disable associated functions as required. Without an integrated EMC filter, it suits integrations where external filtering is chosen depending on compliance needs and installation conditions. This reference enables precise speed control, reduces mechanical shocks at start and stop, and improves consumption management in variable torque applications.

Technical characteristics

• Manufacturer reference : ATV61HD11M3X
• Range : Altivar 61 (ATV61)
• Manufacturer : SCHNEIDER ELECTRIC
• Type : Variable speed drive for three-phase asynchronous motors
• Rated power : 11 kW, 15 HP
• Supply voltage : 240 V three-phase
• Protection rating : IP20, panel mounting
• EMC filtering : no integrated EMC filter
• Control mode : V/f law 2 or 5 points, automatic load adaptation, adjustable and defeatable functions
• Intended use : speed control in industrial process environments

About the ALTIVAR 61 range

The Altivar 61 series targets primarily variable-torque applications, typical of utilities and processes where energy optimisation and service continuity are priorities. Deployed in water, HVAC, food processing, fine chemicals and infrastructure sectors, the range is characterised by straightforward implementation, a wide parameter range and control functions adapted to load variations. In this context, the ATV61HD11M3X provides a level of performance aligned with industrial maintenance and process engineering expectations for 11 kW asynchronous motors.

The IP20 design is intended for installation inside a ventilated electrical enclosure, with installation accessories chosen according to local EMC constraints and applicable standards. The lack of an integrated EMC filter allows the use of externally sized filtering tailored case by case, which facilitates compliance on sensitive or highly instrumented sites. The V/f 2 or 5 point approach, combined with automatic load adaptation, aims to deliver stable control, reduced unnecessary heating and lower mechanical stresses on drive train components.

Industrial applications

The ATV61HD11M3X is suitable for a wide range of applications where speed variation helps control the process and energy use. Typical uses include utilities and transfer stations, as well as auxiliary functions on production lines.

• Pumping and water treatment : flow adaptation, reduction of water hammer, energy-efficient control
• Ventilation and HVAC : airflow modulation for air handling units and extractors
• Conveying and continuous handling : fine speed adjustment for flow synchronization
• Food industry and fluid processing : control of agitation and transfer speeds
• Workshop utilities : fans, circulators and auxiliary drives

Integration and communication

The ATV61HD11M3X drive is integrated into architectures controlled by a programmable logic controller or numerical controller, using digital and analogue inputs/outputs, and, depending on configuration, via optional communication cards provided by the manufacturer. This connectivity enables supervision, logging of speed setpoints and ramp adjustments from the control system, while retaining the basic onboard protections of the drive. Essential parameters of the V/f law and load adaptation functions are accessible from the local interface or via the manufacturer's software tool, in accordance with the technical documentation. In mixed architectures combining frequency drives, servo drives and axis controllers, the ATV61HD11M3X handles the variable-torque drive duties, while dedicated axis controllers manage fast or positional movements. This division of roles improves overall control coherence without complicating maintenance, as settings remain clear and reproducible by engineering and maintenance teams.

For EMC compliance and long-term reliability, shielded motor cabling, proper grounding and the selection of compatible accessories are recommended. The absence of an integrated EMC filter allows for the most appropriate external sizing depending on the site and standards to be met. Panel installation at IP20 requires adequate ventilation and a thermal assessment based on equipment density and drive service duty.
