SI-Ethernet - Interface module - CONTROL TECHNIQUES
This SI-Ethernet interface module from Control Techniques is a programming console from the UNIDRIVE range.
Module compatible with M200, M300, M400, M600, M700 drives
This SI-Ethernet Control techniques interface module is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
SI-Ethernet supports real-time Ethernet (Precision Time Protocol, IEEE 1588 V2), HTTP, SMTP, EtherNet/IP and Modbus TCP/IP. This module provides quick access to the drive, global connectivity and integration with various network technologies, including wireless.
Features include:
• Real-time Ethernet (Precision Time Protocol IEEE 1588 V2), TCP/IP Modbus, EtherNet /IP
• Network synchronization in less than 1 μs (typically < 200 ns)
• 1 ms cycle time for synchronous cyclic data
• Bandwidth protection with a network gateway that manages non-deterministic Ethernet messages
• Master/Slave and peer-to-peer communication capability
• Addressing based on IP
• Two 100 BASE-TX RJ45 connectors with support for 100 Mbps duplex connectivity via shielded twisted-pair cable, and automatic detection of cable crossing
• Built-in switches allow use of networks in sequence (i.e. daisy-chaining)
• Both ports operate in full duplex mode as a network switch
• Network port activity LED indicator
Control Techniques is a leading manufacturer of AC and DC speed variation, servo motors and power conversion technologies for commercial and industrial applications. Their innovative products are used in the most demanding applications, requiring performance, reliability and energy efficiency.
Nidec Control Techniques has been at the forefront of industrial-driven drive technology for more than 40 years. They are dedicated to the advancement of automation. From product development to their headquarters to their 45 automation centers around the world, Nidec Control Techniques provides industry-relevant solutions. They guarantee high performance, reliability and energy efficiency in all applications.
