6SL3000-0HE15-0AA0 - Line filter - SIEMENS
This reference line filter 6SL3000-0HE15-0AA0 and brand SIEMENS is a filter for the SINAMICS/SIMODRIVE 611 ranges.
SINAMICS / SIMODRIVE 611 NETWORK FILTER FOR POWER MODULE ACTIVE 5 KW INPUT: 3PH 380-480 V, 50/60 HZ.
This SIEMENS line filter is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
Optional line filter rows that are coordinated with the power range are also available with the SINAMICS S120 converter system. These line filters differ with regard to the frequency range in which they reduce the conducted emissions.
Basic Line Filter for Active Line Modules
Basic Line Filters function in the frequency range from 150 kHz to 30 MHz. Above all, this protects the radio services.
The Basic Line Filter for Active Line Modules are designed for use in machines in which the conducted interference in the frequency range is to be reduced in accordance with EMC regulations. The machine manufacturer must carry out EMC-compliant CE certification for the product before it is implemented.
The firm that puts the machine on the market takes full responsibility for ensuring CE EMC conformity and that the Basic Line Filter is used correctly. The machine manufacturer (OEM ) must have the machine conformity confirmed.
The Basic Line Filters can be used in accordance with the following general conditions for ensuring CE conformity with regard to conducted interference:
- The machine/system must only be used in industrial networks.
- No. of axes <12.
- Total cable lengths <150 m (motor cables, power supply cable between line filter and Line Module).
Wideband Line Filter for Active Line Modules
The damping characteristics of Wideband Line Filters for Active Line Modules not only conform with the requirements of EMC standards for the frequency range of 150 kHz to 30 MHz but also include low frequencies as of 2 kHz. As a result, these line filters have an extended function area, which means that they can, to a certain extent, be used regardless of the machine installation location and any unknown line properties (e.g. line impedance).
With these line filters, the limit values in accordance with EN 55011, Class A for devices in group 1 are observed. The total cable length must be less than 350 m (motor cables, power supply cable between line filter and Line Module).
Wideband Line Filters also function in the frequency range from 2 kHz to 150 kHz. They help reduce low-frequency line reactions. which protects consumers (e.g. electronic devices) against functional impairments and damage when they are operated on the same network.
With these line filters, the limit values in accordance with EN 55011, Class A for devices in group 1 are observed. The total cable length must be less than 350 m (motor cables, power supply cable between line filter and Line Module).
Line filters for Smart Line Modules
Line filters for Smart Line Modules function in the frequency range from 150 kHz to 30 MHz. Above all, this protects the radio services.
The line filters for Smart Line Modules are designed for use in machines in which the conducted interference in the frequency range is to be reduced in accordance with EMC regulations. The machine manufacturer must carry out EMC-compliant CE certification for the product before it is implemented.
- In conjunction with the line filters and the associated line reactors, drive line-ups with Basic Line Modules fulfill the requirements of limit value class A1 to EN55011.
- The total cable length is ≤ 350 m.
