G730-VOD16-B - I/O Connectors - OMRON
This connector OMRON and reference G730-VOD16-B belongs to the range SYSMAC.
Input module: 16 NPN 24VDC outputs. Communication speed: 187.5 kbps.
This G730-VOD16-B connector is at your disposal to replace your defective hardware and has a warranty adapted to your needs.
Ultra-miniature 4-point, 8-point and 16-point ultra-miniature transistor terminal at affordable prices
Ultra-compact (4-point models: 82 x 32 x 64.5 mm (WxDxH); 8 point / 16 point models: 115 x 32 x 63 mm (WxDxH))
Connection to G730-M / N and Remote I / O (wired SYSMAC BUS).
A series of NPN and PNP input and output models is available (8-point models only).
Two independent power supplies can be used because the I / O terminals are isolated from the internal circuits.
Allows DIN rail mounting with a G730-Y30 DIN rail adapter.
Mounting hole
Use an M4 screw to mount the terminals of the DIP switch.
I / O power terminals
Connect to a 24 VDC power supply.
Internal Circuit Power Terminals
Connect to a 24 VDC power supply.
Transmission terminals
Connect a transmission cable.
Setting the terminal
These terminal pins must be set to ON.
If these terminator pins are set to ON, the terminal resistance is activated. There must be only one terminal in a system. The G730-V located furthest from the G730-M on the transmission path must be the terminator. These pins are factory set to OFF.
