G730-VID16-B - I/O Connectors - OMRON
This connector OMRON and reference G730-VID16-B belongs to the range SYSMAC.
Input module: 16 NPN 24VDC inputs. Communication speed: 187.5 kbps.
This G730-VID16-B connector is at your disposal to replace your defective hardware and has a warranty adapted to your needs.
Ultra-miniature 4-point, 8-point, and 16-point Transistorized Terminals at Affordable Prices
Ultra-compact (4-point models: 82 x 32 x 64.5 mm (WxDxH); 8-point/16-point models: 115 x 32 x 63 mm (WxDxH))
Connecting to both G730-M/N and Remote I/O (wired SYSMAC BUS) Master Units.
A series of NPN and PNP input and output models is available (8-point models only).
Two independent power supplies can be used because the I/O terminals are insulated from the internal circuits.
Allows DIN-track mounting with a G730-Y30 DIN-track Adapter.
Mounting Hole
Use an M4 screw to mount the DIP switch terminals.
I/O Power Supply Terminals
Connect to a 24 VDC power supply.
Internal Circuit Power Supply Terminals
Connect to a 24 VDC power supply.
Transmission Terminals
Connect a transmission cable.
Terminator Setting
These pins of the terminator must be set to ON.
If these pins of the terminator are set to ON, the terminator resistance of the terminator is turned ON. There must be only one terminator in a system. The G730-V located farthest from the G730-M on the transmission path must be the terminator. These pins are factory-set to OFF.
