NX-OD3256 - Output Module - OMRON
This OMRON brand output module and reference NX-OD3256 belongs to the NX-series range.
Features: 24V, 4 points, PNP transistor.
This OMRON module is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
A wide range of high-speed synchronous control general purpose digital I/O units
• I/O modules on the NX CPU or the EtherCAT® coupler Unit
• Connect to NJ/NX/NY controller via EtherCAT
• High-speed I/O refresh using EtherCAT coupler
• I/O refresh synchronized with controller control cycle (synchronous refresh)
• Timestamp inputs and outputs anywhere in the EtherCAT network can be independently controlled with sub-microsecond accuracy
• Detachable terminals for easy maintenance
• Screwless Push-In Plus terminal block or MIL/Fujitsu connector speeds installation
• Compact with a width of 12 mm per unit (connector type: 30 mm)
• 4, 8, 16 or 32 inputs for flexible I/O configuration (NX-ID/IA)
• 2, 4, 8, 16 or 32 outputs for flexible I/O configuration (NX-OD/OC)
• Connection to the CJ PLC using the EtherNet/IPTM bus coupler
A wide range of digital output units from general purpose use to high speed synchronous control
• Transistor and relay output units for the NX series modular I/O system.
• Connect to other NX-series I/O Units and EtherCAT Coupler Units using the high-speed NX bus.
• Synchronous units update their output state according to controller instructions every EtherCAT cycle.
• High-speed I/O refreshing is possible by connecting to the NX-series EtherCAT coupler.
• Output refresh can be synchronized with controller control cycle. (Synchronous refresh)
• The ON/OFF response time of the high-speed model is 300 ns maximum, which enables high-speed and high-precision control.
• The screwless terminal block is detachable to facilitate commissioning and maintenance.
• Screwless clamp terminal block and connector types greatly reduce wiring work.
• Up to 16 digital outputs in a space-saving 12 mm width. (Types of connectors 30 mm wide)
• The range includes 2-point, 4-point, 8-point, 16-point and 32-point types with 3-wire, 2-wire and 1-wire connection methods.
• With updating outputs with a specified timestamp, the output unit updates the outputs at the time specified by the schedule. This enables high-precision output control independent of the controller's control cycle.
