TM3DM8RG

This TM3DM8RG module and SCHNEIDER ELECTRIC brand is a module that belongs to the MODICON TM3 range.

Features: 4x 24Vdc sink/source inputs, 4x 2A relay outputs.

This SCHNEIDER ELECTRIC module is at your disposal to replace your defective equipment and has an appropriate guarantee.

In stock, ready to ship.
State
  • REPAIR SERVICE
Warranty
€190.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



Modicon TM3 range

The Modicon TM3 offer enhances the capabilities of Modicon M221, M221 Book, M241, and M251 logic controllers, Modicon M262 logic/motion controller, and the TM3BC bus coupler modules. The flexibility offered by the TM3 expansion modules systems allows:

- I/O to be remotely located in the enclosure or in another cabinet, up to 5 m (16.40 ft) away, using the bus expansion system

- I/O to be distributed via islands over the networks (Ethernet, CANopen, Serial Line) using the bus coupler modules

Local or remote I/O expansion modules

Digital I/O modules

For creating configurations with up to 488 digital I/O (depending on the controller). These modules are available with the same connections as the controllers. Modules with 8 to 32 inputs/outputs: - 24 V or 120 V c 50/60 Hz inputs - relay or transistor outputs

Analog I/O modules

For creating configurations with up to 114 analog I/O (depending on the controller), designed to receive, amongst other things, position, temperature, and speed sensor signals. They are also capable of controlling variable speed drives or any other device equipped with a current or voltage input. Modules with 2 to 8 inputs/outputs: - voltage/current or temperature inputs - voltage/current or temperature outputs - voltage/current inputs/outputs

Expert modules

For high-speed counting (24 V c inputs ), and event counting with or without event management on fast inputs/thresholds/stop.

For controlling TeSys U motor starters: simplified wiring for the control part connected via RJ45 cables.

TM3 bus expansion modules

Transmitter and receiver modules and bus expansion cable for locating I/O remotely

Safety I/O modules

For integrated machine safety:

- control of Emergency stops

- control of switches

- control of light curtains

- control of pressure-sensitive mats or edges

Bus coupler modules for distributed I/O

For creating distributed I/O islands:

- support for EtherNet/IP, Modbus/TCP, CANopen, or Modbus Serial Line communication protocols

- integration of Web services and cybersecurity (Achilles L1)

- integration of the device identification service from the Modicon M262 logic/motion controller

Specific features

Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data (data synchronization) and provide power during assembly on the bus coupler module, and on the Modicon M221, M221 Book, M241, and M251 logic controllers,and Modicon M262 logic/motion controller.

Connections

The following connections are available on the front face of the expansion modules (depending on the model): - removable screw terminal blocks for the I/O and the power supply (1) - removable spring terminal blocks for the I/O (1) - HE 10 connectors, for use with HE 10/flying leads or HE 10/HE 10 cordsets and Telefast sub-bases (2) The connectors on the bus expansion modules and bus coupler modules are RJ45 connectors.

Mounting

Modicon TM3 modules are mounted on a symmetrical DIN rail 5. They have a locking clip on the top of their casing. For plate or panel mounting, use the TMAM2 kit

Height
9 cm / 3,5 in
Width
8,5 cm / 3,3 in
Length
2,5 cm / 0,9 in
Weight
0,1 kg / 0,2 lb
Family
MODICON TM3
Reference
TM3DM8RG
Refurbished
3000007577205
300007577209

SCHNEIDER ELECTRIC is a French industrial group with international dimension, which manufactures and offers electricity management products, automation and solutions adapted to these trades.

Having consolidated its financial base thanks to the arrival of new shareholders and the simplification of its structures, Schneider began its redeployment at the end of the 1980s. Having joined Merin Gerin in the group (1986), the general management embarked on a acquisition strategy, marked by the integration of important companies that will become the core of the current group:

Télémécanique (1988)

Square D (1991)

Merlin Gerin (1992)

Modicon (1996)
