TM3DI32K - Digital input module - SCHNEIDER ELECTRIC
This TM3DI32K module and SCHNEIDER ELECTRIC brand is a module that belongs to the MODICON TM3 range.
Features: 32 inputs, 24Vdc sink/source
This SCHNEIDER ELECTRIC module is at your disposal to replace your defective equipment and has an appropriate guarantee.
Modicon TM3 range
The Modicon TM3 offer enhances the capabilities of Modicon M221, M221 Book, M241, and M251 logic controllers, Modicon M262 logic/motion controller, and the TM3BC bus coupler modules. The flexibility offered by the TM3 expansion modules systems allows:
- I/O to be remotely located in the enclosure or in another cabinet, up to 5 m (16.40 ft) away, using the bus expansion system
- I/O to be distributed via islands over the networks (Ethernet, CANopen, Serial Line) using the bus coupler modules
Local or remote I/O expansion modules
Digital I/O modules
For creating configurations with up to 488 digital I/O (depending on the controller). These modules are available with the same connections as the controllers. Modules with 8 to 32 inputs/outputs: - 24 V or 120 V c 50/60 Hz inputs - relay or transistor outputs
Analog I/O modules
For creating configurations with up to 114 analog I/O (depending on the controller), designed to receive, amongst other things, position, temperature, and speed sensor signals. They are also capable of controlling variable speed drives or any other device equipped with a current or voltage input. Modules with 2 to 8 inputs/outputs: - voltage/current or temperature inputs - voltage/current or temperature outputs - voltage/current inputs/outputs
Expert modules
For high-speed counting (24 V c inputs ), and event counting with or without event management on fast inputs/thresholds/stop.
For controlling TeSys U motor starters: simplified wiring for the control part connected via RJ45 cables.
TM3 bus expansion modules
Transmitter and receiver modules and bus expansion cable for locating I/O remotely
Safety I/O modules
For integrated machine safety:
- control of Emergency stops
- control of switches
- control of light curtains
- control of pressure-sensitive mats or edges
Bus coupler modules for distributed I/O
For creating distributed I/O islands:
- support for EtherNet/IP, Modbus/TCP, CANopen, or Modbus Serial Line communication protocols
- integration of Web services and cybersecurity (Achilles L1)
- integration of the device identification service from the Modicon M262 logic/motion controller
Specific features
Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. A bus expansion connector is used to distribute data (data synchronization) and provide power during assembly on the bus coupler module, and on the Modicon M221, M221 Book, M241, and M251 logic controllers,and Modicon M262 logic/motion controller.
Connections
The following connections are available on the front face of the expansion modules (depending on the model): - removable screw terminal blocks for the I/O and the power supply (1) - removable spring terminal blocks for the I/O (1) - HE 10 connectors, for use with HE 10/flying leads or HE 10/HE 10 cordsets and Telefast sub-bases (2) The connectors on the bus expansion modules and bus coupler modules are RJ45 connectors.
Mounting
Modicon TM3 modules are mounted on a symmetrical DIN rail 5. They have a locking clip on the top of their casing. For plate or panel mounting, use the TMAM2 kit
