KT5W-2P1213 - Contrast sensor - SICK
KT5W-2P1213
This KT5W-2P1213 contrast sensor is part of the KT5-2 range.
• Light source: red, green, blue LED
• Connection type: M12 connector, 5 pins
• Adjustment: 2-point static teach-in
This SICK brand sensor is at your disposal to replace your defective equipment.
Standard Exchange Service
Reconditioned and tested systems
From 6 to 12
month warranty
Standard Exchange Service
New systems
From 12 to 24
month warranty
Supply Service
Reconditioned and tested systems
From 6 to 12
month warranty
Supply Service
New systems
From 12 to 24
month warranty
Supply Service
Sold for parts – no warranty
Repair service
Repair will be made to damaged and defectiv units
From 3 to 18
month warranty
Fast
delivery
guaranteed
products
Secure
payment
Product description
The KT5-2 contrast sensors are ideal for high-precision contrast detection, for example for detecting marks on high-gloss materials. Thanks to 3-colour LED technology, the sensors activate the best possible emitted light source for each contrast. In addition, the sensors have application-specific learning processes. The sensor automatically sets all necessary parameters, either via the teach button on the device or via an external control cable. The sensor then determines the ideal switching threshold from the two detected grey values. High-precision contrast detection, automatic adaptation for high-gloss objects, detection distances of 10 mm, 20 mm and 40 mm, a switching frequency of 10 kHz and individual alignment and mounting options allow the device to be used for a wide range of tasks. Finally, the 90° rotatable M12 connector enables easy mounting.
At a glance
• Robust metal housing
• Various teaching methods via control panel or control cable
• Maximum detection reliability thanks to 3-colour RGB LED technology
• 10 kHz switching frequency
• Various detection distances and light spot directions
• M12 plug can be rotated 90°
Your benefits
• All print marks and colour combinations are reliably detected, ensuring high machine output
• Reliable operation even with unstable webs and high-gloss materials
• High positioning accuracy improves packaging quality
• Various detection distances, light spot directions and light emissions enable individual configuration and easy integration into the production process
- Height
- 6 cm / 2,3 in
- Width
- 3,5 cm / 1,3 in
- Length
- 9,6 cm / 3,80 in
- Weight
- 0,1 kg / 0,2 lb
- Family
- KT5-2
- Reference
- KT5W-2P1213
300000000674
3000000000663
Founded in 1946, SICK has a worldwide network of nearly 50 subsidiaries and affiliates and numerous agencies. In 2014, SICK employed about 7,000 people worldwide.
SICK is one of the leading manufacturers of sensors, both for production automation and for industrial analysis and logistics automation. As the leading technology and market leader, SICK offers sensors and solutions for industrial applications that provide an ideal basis for safe and efficient process management, protecting people from accidents and preventing environmental damage.
