6SE6440-2AC24-0CA1 - Inverter - SIEMENS
This reference inverter 6SE6440-2AC24-0CA1 and brand SIEMENS is a variable speed drive of the range MICROMASTER 440.
MICROMASTER 440 WITH FILTER 3AC 200-240 V +/- 10% 47-63 HZ CONSTANT TORQUE POWER 4 KW OVERLOAD 150% 60 S, 200% 3 S SQUARED POWER OUTPUT 5.5 KW.
This SIEMENS drive is at your disposal to replace your defective equipment and has a suitable warranty.
The MICROMASTER 440 inverter is suitable for a variety of variable-speed drive applications. Its flexibility provides for a wide spectrum of applications.
These also include cranes and hoisting gear, high-bay warehouses, production machines for food, beverages and tobacco packaging machines etc. applications which require the frequency inverter to have a higher functionality and dynamic response than usual.
The inverter is especially characterized by its customer-oriented performance and ease of use. Its large supply voltage range enables it to be used all over the world.
The MICROMASTER 440 The MICROMASTER 440 has a modular design.
The operator panels and the modues can be easyly exchanged.
■ International Standards
The MICROMASTER 440 inverter complies with requirements of the EU low-voltage guideline ; filtered versions also comply with EU EMC guideline.
The MICROMASTER 440 inverter has the EU marking.
- Simple commissioning.
- Modular construction allows maximum configuration flexibility.
- Six programmable isolated digital inputs
-Two scalable analog inputs (0Vto10V,0mAto20mA) can also be used as a 7th/ 8th digital input.
- Two programmable analog outputs (0 mA to 20 mA)
- Three fully programmable relay outputs (30 V DC/5 A, resistive 250 V AC/2 A, inductive)
- Silent motor operation is selectable when using high switching frequencies (observe derating if necessary)
- Complete inverter and motor protection.
