631-001-230 - Digital servoamplifier - PARKER
This reference 631-001-230 and PARKER brand servo drive is a servo drive from the SSD DRIVE range and 630 series.
631-001-230: 230V single-phase or three-phase 50/60Hz, 1A/2A
This PARKER servo drive is at your disposal to replace your defective equipment and has an appropriate guarantee.
DESCRIPTION
Directly connected to the 230V network, the 631-635 servo drives offer numerous possibilities for controlling torque, speed and positioning. Integrating a positioner, EMC filter and braking module, the 635 is available in a compact or rack version (up to 9 drives). More than a simple servo drive, the 631 integrates PLC functions and I/O extension possibilities.
Positioner 1500 program steps
Internal EMC filter
Integrated braking module
Direct 230 Vac power supply
Wall mounting or DIN rail (631)
Compact or rack version (635)
CANopen interface as standard (631)
Fieldbus options (635)
TECHNICAL SPECIFICATIONS
Food
- 230Vac ±10%; single-phase or three-phase
Temperature
- 0-40°C (derating of 2% per °C >40°C up to 50°C max.) - Altitude 1000m (derating of 1% per 100m increment up to 4000m max.)
Humidity
-85% relative humidity without condensation
Regulation 631-635
Current loop 210 µs Speed loop 630 µs Position loop 1890 µs
631:
Entries exits
4 - Digital inputs, configurable (24V)
2 - Logic outputs, configurable (24V)
1 - Analog input (+/- 10V) Optional I/O extension module
8 - Digital inputs/outputs, configurable -4 outputs max.)
Solver input
Pulse train input and output
RS232 programming port
CAN bus input and output
635:
Entries exits
8 - Logic inputs (including 2 200µs interrupts)
5 - Logic outputs (3 x Opto-coupled, 2 x Relay)
2 - Analog inputs (-10V / 0 / +10V)
2 - Analog outputs (+/- 10V)
Solver input
Encoder (Configurable as input or output)
Communication Options
RS232 PROFIBUS-DP
RS422 INTERBUS S
RS485 SUCOnet K
CANbus
I/O expansion options
5 logic inputs/2 additional logic outputs
