ATS22D47Q - Starter - SCHNEIDER ELECTRIC

The Altistart 22 soft starter provides progressive starting and stopping in voltage and torque of three-phase squirrel-cage asynchronous motors, for powers between 4 and 400 kW. It is delivered ready to use for a standard application with class 10 motor protection. ease of implementation. To better meet certain applications which require the ability to short-circuit the starter at the end of starting, for example to limit the heat dissipation emitted by the starter, the use of the bypass function (bypass contactor) has been made easier by its integration in the starter. The Altistart 22 soft starter has an integrated terminal for modifying the programming as well as the adjustment or monitoring parameters to adapt and personalize the application to the customer's needs. It also incorporates motor thermal protection as well as machine monitoring and ensures immediate implementation of the installation thanks to the SoMove commissioning software.

The functions integrated into the Altistart 22 soft starter-soft stop respond to the most common applications encountered in the building, infrastructure or industrial sectors:

- centrifugal pumps, piston pumps,

- fans,

- screw compressors, ...

- handling (conveyors, ...),

- specialized machines (agitators, mixers, centrifugal machines).

The Altistart 22 starter-retarder offers a truly economical solution because it allows you to:

- reduce installation costs by optimizing the size of products, integrating the bypass function and reducing wiring times,

- reduce electrical distribution stresses, by reducing current peaks and line voltage drops associated with motor start-ups,

- reduce machine operating costs by reducing mechanical stress.

The control of the three motor winding phases guarantees performance in any situation (presence or absence of load, any range of voltages or powers, etc.).
