E82EV223K4B201 - Frequency Converter - LENZE

LENZE 8200 Vector E82EV223K4B201, 22 kW inverter for precise, long-lasting vector control

Designed for industrial drive applications, the LENZE 8200 Vector E82EV223K4B201 frequency inverter meets demands for speed and torque control on asynchronous motors. It addresses the needs of maintenance managers, automation engineers, integrators and OEMs who require reliable hardware, fast availability and easy cabinet integration. Its 3 x 400/500 V three-phase supply simplifies deployment across international sites, while the 22 kW rating covers a wide range of standard applications. Vector control delivers a stable response even under varying load conditions. The coated version, with protective varnish on the electronic boards, improves resistance to contaminated atmospheres, extending service life in demanding industrial environments. The execution without integrated EMC suppression allows you to select the most appropriate external EMC filter according to your installation and regulatory constraints.

Measurable benefits for your production

• Process control – Vector control enables precise regulation of speed and torque, ensuring consistent quality on lines with variable load.
• Network compatibility – 3 x 400/500 V supply, facilitating multi-site deployment and standardisation of your drive fleet.
• 22 kW capacity – Covers a broad range of standard applications, well sized for mid-range asynchronous motors.
• Durability in harsh environments – Coated version protects electronics against ambient humidity and fine dust, contributing to long-term reliability.
• Controlled EMC compliance – No integrated filter, so you can choose the external filter best suited to meet your site’s electromagnetic requirements.

Modular architecture and design quality

Part of the 8200 Vector range, this frequency inverter features a modular architecture designed to simplify control, diagnostics and communication. The unit supports vector control of asynchronous motors and is designed for cabinet installation for easier maintenance. The reference E82EV223K4B201 corresponds to a 22 kW unit, intended for a 3 x 400/500 V three-phase supply. The coated finish applies a protective varnish to the circuit boards, useful in workshops where the air may contain particles or high relative humidity. The device is specified as having no integrated EMC suppression measures, which points to adding an external EMC filter selected according to the environment, cabling and applicable standards. The modular philosophy of the series allows adapting control and communication interfaces as needed while keeping commissioning straightforward and diagnostics accessible.

Target applications and operating contexts

The 8200 Vector E82EV223K4B201 is suitable for standard industrial drives requiring reliable speed holding and a stable response to load variations. It is typically used on conveyors, assembly machines, material handling systems, packaging lines or continuous processes where throughput consistency and repeatability are priorities. Its 22 kW power and 3 x 400/500 V supply make it a relevant choice for mid-size equipment in production workshops, logistics centres or process units.

Differentiation, robustness and LENZE expertise

LENZE’s 8200 Vector series is recognised for industrial reliability and a modular approach that eases integration and maintenance. The coated version offers additional board protection, valuable in harsh ambient conditions. The absence of an integrated EMC filter gives design freedom to achieve electromagnetic compliance with an appropriate external filter. Backed by LENZE expertise, this inverter supports parts availability, continuity of service and reproducible field performance.

Get back into production faster with Standard Exchange Industry through standard exchange options, refurbished supply or repair, and short lead times. Contact our team to validate electrical compatibility, select the appropriate external EMC filter and secure your supply.
