E82EV371K2C - Frequency Converter - LENZE

LENZE 8200 Vector E82EV371K2C, 0.37 kW drive for reliable control in industrial environments

The LENZE 8200 Vector E82EV371K2C frequency inverter is aimed at maintenance managers, automation engineers and integrators who require stable, repeatable speed control for low-power motors. With a nominal power of 0.37 kW and a single-phase 230/240 V supply, it integrates easily into existing installations without network redesign. Its wide input range of 180 to 264 V and compatibility with 45 to 65 Hz mains ensure high tolerance to supply variations, a practical advantage in operation. From the 8200 Vector range, this model provides performance-oriented control for driving conveyors, fans, pumps and machines that require precise speed variation. It is a robust solution for both retrofits and new projects, with predictable behavior that secures line availability.

Operational benefits focused on performance and availability

• Integration on 230 V single-phase networks – Direct connection to common supplies, simplifying installation and commissioning.
• Input range 180 to 264 V, 45 to 65 Hz – Tolerates mains fluctuations, contributing to process stability and reducing unplanned downtime.
• Rated power 0.37 kW – Proper sizing for light conveyors, fans and service pumps, with reliable speed control.
• Current reserve up to 60 s – Maximum output current 3.6 A for 60 s to absorb temporary load peaks and handle starting efforts.
• Wide motor compatibility – Drives asynchronous, reluctance and permanent magnet synchronous motors, facilitating standardization across a diverse fleet.

Key technical features and build quality

The LENZE E82EV371K2C belongs to the 8200 Vector series, designed for precise speed control of industrial motors. Reference data include a rated power of 0.37 kW, a single-phase AC 230/240 V supply with an input range of 180 to 264 V and a mains frequency of 45 to 65 Hz. The nominal input current is 5.0 A without upstream inductance and 4.2 A with upstream inductance, allowing adaptation of the electrical architecture according to EMC or network constraints. The rated output current reaches 2.4 A and the maximum current 3.6 A for up to 60 seconds, providing useful margin for accelerations or load transients. Compatibility with asynchronous, reluctance and permanent magnet synchronous motors expands the possible application range. The design adheres to LENZE industrial standards, with clear parameter logic and stable operation sought for production environments. These specifications form a proven technical basis for continuous or intermittent applications where speed control is a critical factor for quality and productivity.

Typical applications and use cases

Assembly, discharge or sorting conveyors, process or smoke-extraction fans, small circulation or dosing pumps, all situations where the E82EV371K2C delivers reliable, repeatable speed variation. Maintenance teams will find it suited to retrofitting equipment powered by single-phase 230 V, while integrators will secure adherence to speed setpoints and absorption of transient efforts. Precise control helps reduce mechanical wear and jerking, improving component lifespan.

Differentiation, brand reliability and SEI support

LENZE is recognised for drive solutions focused on control precision and operational consistency. The 8200 Vector series is positioned to meet speed-control needs with an architecture that is easy for technical teams to understand. By relying on Standard Exchange Industry, you benefit from quick availability, exchange units, supply of new or refurbished units, and qualified repair services. Warranties from 6 to 24 months depending on the service, combined with delivery times of 24 to 72 h, support your objectives for rapid restart and long-term reliability.

Need an express provision of the LENZE E82EV371K2C or a repair quote for your existing drive, including for production emergencies? Contact our specialists. We help you confirm power, voltage and motor type compatibility, then secure the restart as quickly as possible.
