E94P020T4N - Frequency Converter - LENZE
This reference frequency drive E94P020T4N and LENZE brand is a drive from the PositionServo range.
Frequency converter: 400/480V, 3 phase, 2A.
This LENZE E94P020T4N drive is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
The PositionServo is the one drive that has it all. From basic torque control to full programmability, you choose your level of control. As a distributed drive/controller solution, avoid all of the costly cables and connections and put the power of the motion controller in the same package as the drive. The PositionServo can perform along with the most high-level motion controllers, but with a simple-to-use interface and clean Ethernet connection. If a centralized control scheme is preferred; the PositionServo will outperform most torque or velocity amplifiers. It is also packed with many features, all this for a great price!
Motion Control Features
• 64-bit indexing/positioning (incremental, absolute, registered, or segmented moves)
• Linear or S-Curve accel and decel
• AutoTuning and “Real-time” Oscilloscope
• Free program examples
Drive Features
• Torque, velocity and position control
• Electronic gearing
• UL, cUL, CE(LVD & EMC)
• ISO13849-1 safety standard (optional)
• Two-year warranty
Inputs/Outputs
• 11 Programmable + 1 dedicated digital input
• 4 Programmable + 1 dedicated digital output
• 2 Programmable analog inputs
• 1 Programmable analog output
Communication Features
• Free MotionView OnBoard
• RJ-45 Standard Ethernet Modbus TCP/IP, Ethernet IP
• Optional DeviceNet, RS485 PPP or Modbus RTU slave, CANopen, PROFIBUS-DP
Power Features
Standard Drives
• 80 – 528 VAC input
• 2 – 18 Amps continuous rms current
• 300% peak current
Doubler Drives
• When operating at 120VAC, Doubler Drives can run 240VAC motors at full speed.
Feedback Options
• Integrated Encoder
• Integrated Resolver
• Optional Second Encoder Module
Compatible Motors
• MCS Series
• Third party AC permanent magnet synchronous (brushless) motors
• Encoder or resolver feedback
Lenze specializes in automation and drive technologies and is established in more than 60 countries. They develop, manufacture and sell innovative products, global solutions and complete systems.
