FCS01.1E-W0019-A-02-NNBV - Frequency Converter - INDRAMAT
This INDRAMAT reference frequency converter FCS01.1E-W0019-A-02-NNBV is part of the IndraDrive FC series.
Converter frequency : 19A. Design 1. 1xAC 200 ... 240V
This INDRAMAT drive is at your disposal to replace your defective equipment and has an adapted guarantee.
Drive tested on engine test bench.
The Rexroth IndraDrive Fc drive system comprises the individual components (the system elements) which are required for application and utilization in the respective case:
• FCS01 frequency converter
• FCC01 function module
• FWA-INDRV*-FCB firmware
• Standard asynchronous motor
• Power transformer as an optional component
• Mains filter as an optional components
• Mains choke as optional components
• Braking resistor as additional component
Compared to the units HCS02 and HCS03 of the IndraDrive C product family, the FCS01 units of the IndraDrive FC product family display a narrower power range, and their functionality scalability is smaller than that of the former. Primarily the FCS01 unit specialize in OpenLoop operation.
It is not possible to couple the FCS01 units via a shared DC bus to the HCS02 units.
Properties of the basic device FCS01:
• Permitted ambient temperature 0 to 50°C
• Degree of protection IP20 (for installation of control cabinet)
• Can be mounted next to each other without any additional space inbetween
• Power range from 0.25 kW to 7.5 kW (1/3~ 230V for 0.25kW to 2.2kW, 3~ 400V for 0.55kW to 7.5kW)
• Supply voltages 230 V and 400 V, 1- and 3-phase;
• Integrated EMC mains filter for limit curve A according to EN55011
• High start-up torque and precise motor speed control
• Overload capacity up to 200% over 3.5 s, and 150% over 60 s
• Output frequency 0....400Hz
• Settable pulse frequencies of 3.0…16 kHz
• Integrated brake chopper for 4-quadrant-operation (braking resistor can be connected externally)
• Materials free of asbestos and silicone
Indramat is an industrial company founded in 1958, based in Neuwied, Germany.
Indramat Gmbh , which is now part of Bosch Rexroth , was an industrial control company founded in 1958, based in Neuwied (am Rhein), Germany. Its name is a German abbreviation meaning «Gesellschaft zur IND ustrialisierung- RA tionalisierung und Auto MAT isierung».
