A06B-6105-H003 - Servo Amplifier - FANUC
Includes a 6-axis A16B-2000-0063/06C power board, and a servo control board A16B-3200-0440/04C
This A06B-6105-H003 drive is at your disposal to replace your defective hardware and has a warranty adapted to your needs.
Applicable CNC
FANUC Series 30i/300is/300i, FANUC Series 31i/310is/310i A5, FANUC Series 31i/310is/310i, FANUC Series 31i/310is/310i, FANUC Series 32i/320is/320i.
Number of controlled axes
- Series 30i/300is/300i : 32 maximum
- Series 31i/310is/310i A5 : 20 maximum
- Series 31i/310is/310i : 20 maximum
- Series 32i/320is/320i : 9 maximum
Number of spindle controlled axes
- Series 30i/300is/300i : 8 maximum
- Series 31i/310is/310i A5 : 6 maximum
- Series 31i/310is/310i : 6 maximum
- Series 32i/320is/320i : 2 maximum
Amplifier
- α series servo amplifier, α series spindle amplifier, α series power supply module, αi series servo amplifier, βi series servo amplifier, αi series spindle amplifier, αi series spindle amplifier
Motor
- α series servo motor
- α series spindle motor
- β series servo motor
- αi series servo motor
- αi series spindle motor
- αis series servo motor
- βis series servo motor
- Lis series linear motor
I/O
- I/O unit (I/O Link)
Software
- Dual check safety software option
DETECTOR SYSTEM
The detectors below can be used.
Feed axis detector
-Pulsecoder αA1000, αA64,
- αA16000i, αA1000i, αI1000i, αA64i
- βA64B, βA32B
- βI64B, βI32B
- Separate type detector (A quard B)
Spindle detector
- M sensor, MZ sensor, BZ sensor, Mi sensor, MZi sensor, MZi sensor, BZi sensor, CZi sensor.
High Resolution Serial output circuit
