6SL3210-1KE23-2UB1 - Servo drive - SIEMENS
This SIEMENS servo drive bears the reference 6SL3210-1KE23-2UB1. It corresponds to the range of SIEMENS - SINAMICS G120C servo drives.
SINAMICS G120C RATED POWER 15.0KW WITH 150% OVERLOAD FOR 3 SEC 3AC380-480V +10/-20% 47-63HZ UNFILTERED I/O INTERFACE: 6DI, 2DO,1AI,1AO INTEGRATED SAFE TORQUE OFF INTEGRATED FIELDBUS: USS/MODBUS RTU; PROTECTION DEGREE IP20/ UL OPEN TYPE SIZE: FSC 295X140X203 (HXLXP) EXTERNAL 24V
SIEMENS servo drive reconditioned and tested on manufacturer test bench (100% test).
SINAMICS G120C compact drives offer a well-balanced combination of features to meet a wide range of applications. They are compact and robust devices, easy to use and can be optionally equipped with a basic or advanced panel operator.
SINAMICS G120C drives are particularly suitable when it comes to meeting the requirements of system integrators, OEMs and distributors for high productivity and tailor-made performance.
SINAMICS G120C is a compact drive for control cabinet installation in degree of protection IP20 where the Control Unit (CU) and the functional units Power Module (PM) are combined in a single device. The compact mechanical design and high power density allow these devices to be installed in machine control enclosures and control cabinets for maximum space utilization. The SINAMICS G120C compact drive can be directly butt-mounted without derating at temperatures up to 40 °C.
Benefits
• Compact design
• Side-by-side design
• High power density, small envelope dimensions
• Simple installation in the tightest space
• Small footprint
• Use in small control cabinets close to the machine
• Optimized parameter set
• Optimized commissioning
• Getting started document
• BOP-2 or IOP Operator Panels can be used
• Integrated USB connection
• Simple and fast software configuration
• Easy to use during commissioning and operation
• Minimized training costs, existing SINAMICS know-how can be used
• High serviceability, simple maintenance
• Plug-in terminals
• Cloning function using BOP-2, IOP or memory card
• Operating hours counter for "drive running" and "motor running"
• Quick mechanical installation
• Intuitive standard commissioning
• Fully integrated automation component
• Sensorless and energy-efficient vector control
• Automatic flux reduction with V/f ECO
• Integrated energy saving computer
• Integrated Safety (STO)
• Communication versions with PROFINET / EtherNet/IP, PROFIBUS DP, USS/Modbus RTU
• Coated modules
• Operation up to an ambient temperature of 60°C (140°F)
