SPD 1.35-S0-0 - Spindle drive module - FAGOR
This FAGOR spindle drive module is reference SPD 1.35-S0-0. It belongs to the FAGOR DIGITAL SERVO DRIVE SYSTEM range.
Power supply 400/460Vac. Control circuit: 24V, 0.9A.
This SPD 1.35-S0-0 axis drive module is at your disposal to replace your defective equipment and has a guarantee adapted to your needs
Spindle drive module tested on FAGOR engine
MODULAR SYSTEM
It is a configurable system that controls several axes ant the spindle.
The power supply module (PS, XPS or RPS) is connected directly to 400-460Vac mains and it supplies to the servo drive modules installed :
- Axis drives (AXD)
- Spindle drives (SPD)
COMPACT SYSTEM
They are independent drives with a integrated power supply and may be connected directly to mains.
There are compact drives to control a single axis (ACD) or a single spindle (SCD).
DRIVE CONFIGURATION
- Direct feedback (optional)
Real axis position feedback, ususally through a linear or rotary encoder.
Encoder simulator board (optional)
It outputs a number of pluses per motor turn that can be set by parameter (any value between 1 and 16,384 ppt, programmable reference mark (Io), (differential TTL)
Motor feedback board
It reads the feedback signals coming from the encoder mounted on the motor in order to know the exact rotor position and speed.
RS-232 C Board
To connect it with a PC or a programming module for aprameter setting and system monitoring (between 9,600 Baud and 19,200 Baud).
Digital sercos interface board (optional)
Precise and efficient fiber optic interface using the SERCOS communications standard to transmit position, velocity and torque commands. The use of fiber optics ensures full immunity against noise and extremely simple cabling between modules.
Digital can interface card (optional)
Standard CAN communications interface to transmit position, velocity and torque commands.
Analog interface board (optional)
It offers 2 - 10 V analog inputs and 2 analog outputs to connect the CNC velocity commands and to monitor internal parameters respectively. It also offers 4 digital inputs and 4 digital outputs, all of them fully programmable.
FAGOR AUTOMATION is a company with extensive experience in the development and manufacture of machine automation and control products. It differentiates itself by its software development capacity and the flexibility of its productive system to offer customized solutions, according to customer needs.
Historically, FAGOR AUTOMATION has focused its efforts on the machine tool sector, where it is one of the world leaders. It has a vast commercial and technical network in more than 50 countries, through its own subsidiaries and distributors.
