6SE7011-5EP50 - Inverter - SIEMENS
Inverter 6SE7011-5EP50 and SIEMENS brand inverter. MASTERDRIVES Motion Control. This inverter belongs to the SIMOVERT range.
SIMOVERT MASTERDRIVES MOTION CONTROL COMPACT PLUS THREE-PHASE CONVERTER 380-480 V, 50/60 HZ, 1,5A. TYPE POWER : 0.55kW
This Siemens 6SE7011-5EP50 inverter is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
SIMOVERT MASTERDRIVES MC (Motion Control) are part of the SIMOVERT MASTERDRIVES product group which is a complete digital frequency variation system for variable speed drives with three-phase motors. The numerous hardware variants combined with various control functions allow optimum adaptation to the most varied applications.
The regulation functionality is established by the software contained in the converter and inverter modules. The SIMOVERT MASTERDRIVES product group includes the following control functions:
♦ Vector Control (VC) vector control for demanding applications in terms of precision and dynamics
♦ Motion Control (MC) vector control for servomechanisms, under the optional control of technological functions.
The SIMOVERT MASTERDRIVES product group consists of the following components:
♦ indirect converters (full converters)
♦ inverters
♦ power supply units (EE)
♦ power / recovery units (ER, AFE)
♦ braking units and braking resistors
♦ capacitor module (CM)
♦ coupling module
♦ intermediate circuit bars
♦ network filter
♦ mains side switching reactors
♦ fuses
♦ optional cards:
- Sensor Boards (SBx) for speed measurement and positioning
- Communication Boards (CBx) for connection to the field bus
- SIMOLINK (SLx) for the rapid transmission of instructions and
measures
♦ software options
♦ accessories
The Motion Control regulation functionality covers the needs of the servomechanisms. The current vector regulation in conjunction with a very short sampling period allows rapid metering of the current injected into the windings of the motor and thus provides high torque build-up dynamics.
Current regulation is applicable to synchronous and asynchronous motors. The detection of the position of the rotor and / or the speed of rotation can be provided by various types of sensors.
The motion control function is available in both indirect converters and inverters. They are sized for a mains voltage range of 380 V - 15% to 480 V + 10%.
All devices have an extensive basic functional repertoire. It can be extended by software and hardware options offering technological and communication functions. Adaptation to the needs of various applications is thus guaranteed. All control functions are performed by freely interconnectable functional blocks. This freedom of combination provides the flexibility required to adapt the
software to the intended application.
In conjunction with the various dialogue means, the software menus integrated into the devices facilitate commissioning and monitoring of the drives. PC-based tools provide the efficient resources for setup and backup.
Power components (indirect converters, inverters,
power supply units, supply / recovery units) used for the realization of the Motion Control regulation functionality are available in three construction forms. At the level of indirect converters and inverters, we have the correspondence between form and
power :
♦ Compact PLUS form 550 W to 18.5 kW
♦ Compact form 2.2 kW to 37 kW
♦ built-in form 45 kW to 250 kW
