4PP151.0571-21

This B&R touch panel reference 4PP151.0571-21 is part of the POWER PANEL 100/200 range.

Power Panel PP151 5.7" QVGA color LC-display; 6 softkeys; 16 function keys and 20 system keys; 16 MB SDRAM; Compact Flash slot (type I); ETH 10/100; RS 232; 2xUSB; metal housing, IP 65 protection (front side); 24 VDC

This B&R terminal is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.

Device 100% tested.

In stock, ready to ship.
State
  • REPAIR SERVICE
Warranty
€900.00

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



B&R offers the B&R Power Panel 100 and Power Panel 200 product ranges for automating small to mid-sized machines and systems.

The Power Panel 100 and Power Panel 200 product range encompasses a line of devices from operator panels with QVGA, VGA or XGA displays to visualization and machine control. Programmable with Automation Studio (Visual Components), these devices close the gap between Panelware and IPC-based systems. Depending on the design, the devices contain the embedded operating system Automation Runtime or a BIOS-based operating system such as Windows CE or Windows XP Embedded. The number of onboard interfaces is reduced to a minimum and size is optimized to the smallest dimensions.

Depending on the variant, the devices have a 5.7" QVGA touch screen available in color or black/white, a 10.4" VGA, a 12.1" SVGA, or a 15" XGA touch screen in color. In addition, there are horizontally or vertically formatted devices available (numeric and alphanumeric keys, with/without legend strips) for all display sizes (exception: 12.1" SVGA - only available without keys and with touch screen).

• 24 VDC supply voltage

• 2 USB 1.1 connections

• Ethernet 10/100 MBit interface

• CompactFlash card (type I) slot

• RS232 interface, modem-capable, not electrically isolated

• 2 operating mode switches (2 x 16 digit)

• 2 status LEDs (User or CompactFlash card access)

• Fan-free operation • Touch screen (analog resistive), function keys or both1)

• Filter glass (multiple-coated, non-reflective)1)

• Horizontal and vertical mounting orientations, numeric and alphanumeric keys1)

• Software compatible with B&R 2000 PLC family

• Maximum 2 aPCI slots (see B&R System 2005 User's Manual for available aPCI interface modules)1)

• BIOS or Automation Runtime operating system1)

• Real-time clock (battery-buffered)1)

• Up to 128 MB SDRAM main memory1)

Height
6 cm / 2,3 in
Width
21 cm / 8,2 in
Length
24.5 cm / 9.64 in
Weight
2 kg / 4,4 lbs
Family
POWER PANEL 100/200
Reference
4PP151.0571-21

B&R is an Austrian company founded in 1979 by Erwin Bernecker and Josef Rainer in Eggelsberg near Salzburg.

B&R provides complete solutions in industrial automation.

Range of extended products programmed and configured using Automation Studio software.
