AFP0RT32CT - FP0R-T32CT - I/O module - PANASONIC
Central unit with PANASONIC transistor outputs reference AFP0RT32CT - FP0R-T32CT. FP0R series.
Features : 16 inputs, 16 NPN outputs, RS232C, integrated battery.
This PANASONIC automaton is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
Ultra-compact with enhanced features
Thanks to its compact dimensions, the FP0R is particularly suitable for small control cabinets and confined spaces. It allows up to four axes to be positioned without an expansion module and its TOOL USB port facilitates rapid program transfer. The FP0R particularly stands out in demanding environments such as labeling applications.
FP0R: improved performance and features
FP0R CPUs offer you the following optimized features.
FP0R: ultra-compact dimensions, identical to the FP0
The central unit of the FP0R has the same dimensions as the FP0: L25 x H90 x D60mm. You can connect up to 3 FP0 expansion modules to the FP0R and have 128 inputs/outputs for a total width of just 100mm!
FP0R: fully compatible with FP0 central units
The FP0R CPUs have the same dimensions, colors, pin assignments and wiring as the FP0 CPUs. The FP0R allows you to use the FP0 programs without having to modify them. So, you can replace an FP0 with an FP0R without difficulty. Of course, all FP0 expansion modules are compatible with the FP0R.
Ultra-fast processing improving productivity
Ultra-fast processing speed of 0.08µs/step for basic instructions and the first 3000 steps, 0.58µs/step for subsequent ones. The FP0R is ideal for automated processing and positioning applications, such as in labeling machines.
Large programming capacity of 16k or 32k steps
Large data register of 12k or 32k words
Independent comment memory
USB2.0 port for extremely fast program transfer
Backup of all your data without batteries and almost without maintenance with the FP0R type F. A first in this sector!
Extremely advanced, integrated positioning functions
Operation JOG
Individual settings for controlling acceleration and deceleration ramps
Setpoint speed changeable via external signal input during JOG operation or trapezoidal control
Ability to read encoder signals up to 50kHz (measurement of pulse output frequency)
6-channel high-speed counters and pulse outputs for controlling 4 axes, usable simultaneously
FP0R units offer various network communication possibilities using an integrated interface or expansion modules
Ethernet (Modbus TCP/IEC60870)
Profibus
CC-Link
MEWNET-W0
C-NET
RS232 or RS485 serial communication
Panasonic offers a diverse portfolio of products and over 40 years of design expertise to provide integrated solutions that fits into various automation markets such as Automotive, Semiconductor, Packaging and Bio Medical. Boasting a strong reputation for quality, an established organization of highly experienced professionals and technically advanced products, Panasonic strives to be your trusted partner.
