X67BC81RT.L12 - Bus module - B&R

Reference X67BC81RT.L12

This B&R module is reference X67BC81RT.L12. It belongs to the X67 range.

X67 bus controller, 2 POWERLINK interfaces, X2X Link power supply 15 W, reACTION Technology module, 2 digital inputs, 24 VDC, <1 µs, 3 digital channels, 5 VDC, <1 µs, configurable as inputs or outputs, 2 digital channels, 24 VDC, 0.4 A, <1 µs, configurable as inputs or outputs, 2 analog inputs ±10 V, 5 µs 200 kHz sampling frequency, 13-bit converter resolution including sign, configurable input filter, 1 analog output ±10 V, 2.5 µs, 13-bit converter resolution including sign, M12 connectors, high-density module

This B&R module is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.

In stock, ready to ship.

State

Refurbished Supply

Warranty

€700.00

VAT excluded

System options

Fast
delivery

guaranteed
products

Secure
payment

X67 modules have a plastic housing for use in harsh industrial environments. The devices are fully sealed and therefore extremely resistant to mechanical stress. Integrated LEDs provide clear status indications on the machine, logically distributed on the individual channels, for the X2X Link status and the entire I/O section. Solutions such as central fastening using two screws allow easy installation, even when using wedge nuts in standard aluminum frames.

X67 is an I/O solution for all standard fieldbus systems and for direct connections to B&R controllers. The fieldbus may change, but the I/O system always remains the same.

Optimal ergonomics and an extremely compact design allow the X67 system to fit anywhere on the machine

Digital channels that can be configured as inputs or outputs allow the solution to be tailored to the requirements and reduce the total number and variety of modules needed.

Visual status indicators on the modules and advanced status messages via the bus enable clear-cut diagnostics. Warning and error thresholds for I/O power supply, single-channel diagnostics and open-circuit detection are just a few examples.

100 m module spacing without limitations offers sufficient reserves, regardless of whether modules sit close together or distances must be covered.

These completely sealed modules are the epitome of robustness, with features for maximizing electromagnetic immunity (EMC) hidden inside.

Cycle times well below one millisecond ensure the necessary reserves for your application. Synchronous I/O processing is a matter of course

Pre-assembled standard cables and automatic module identification reduce installation and commissioning work to an absolute minimum.

Communication and I/Os are completely galvanically isolated. Disturbances or voltage drops on the I/O side have no influence on the functionality of the bus. Diagnostics is always possible.

Integrated reverse polarity protection, short-circuit protection, protection when switching inductances – the highest degree of protection for the electronics as well.

I/O power via 2 pairs of leads provides up to 8 amps for outputs or supplies additional modules.

Many sensors and actuators require a 24 VDC power supply. With X67 modules, this is integrated in all digital connections and also provides protection against short circuits.

Seamless 360° shield grounding from the cable over the connector directly on the threading of the M12 connector, through to the metal backplane of the module and over the mounting screws straight to the machine provides a complete ground connection for all bus and analog signals.

X67 systems can be expanded by 250 modules with up to 100 m between them.

The central position of the two mounting screws prevents misalignment of the housing in standard aluminum frames with wedge nut installations

Many sensors and actuators require a 24 VDC power supply. With X67 modules, this is integrated in all digital connections and also provides protection against short circuits.

Height: 5 cm / 1,9 in
Width: 4 cm / 1,5 in
Length: 8,5 cm / 3,3 in
Weight: 0,3 kg / 0,6 lb
Family: X67
Reference: X67BC81RT.L12
