CJ1W-OD212 - I/O module - OMRON

A wide range of basic outputs

Units for high speed output and different applications

• These output units receive the results of output instructions from the CPU and perform ON/OFF control for external devices.

• High speed output models CJ1W-OD213 and CJ1W-OD234 can help increase system throughput.

Features

• High-speed output models are available, meeting versatile applications. ON response time: 15 μs, OFF response time: 80 μs

• Output units are available with one of three output types: relay contact outputs, triac outputs, or transistor outputs.

• For transistor outputs, choose from negative outputs or source outputs.

• Output units with load short circuit protection are also available. *1

• Select the best interface for each application: Fujitsu connectors or MIL connectors. *2

• A wide variety of connector-to-terminal conversion units are available to allow you to easily wire external output devices.

*1. The following units have load short circuit protection: CJ1W-OC202, CJ1W-OD204, CJ1W-OD212 and CJ1W-OD232.

*2. Available for models with 32 outputs or 64 outputs

​International standards

• The standards are abbreviated as follows: U: UL, U1: UL (Class I Division 2 Products for Hazardous Locations), C: CSA, UC: cULus, UC1: cULus (Class I Division 2

Products for hazardous areas), CU: cUL, N: NK, L: Lloyd and CE: CE directives.

• Contact your OMRON representative for further details and conditions applicable to these standards.
