ATV61HU30M3 - Speed drive - SCHNEIDER ELECTRIC

SCHNEIDER ELECTRIC ATV61HU22M3 - Altivar 61 frequency drive

The drive model ATV61HU22M3 belongs to the Altivar 61 range from SCHNEIDER ELECTRIC. Designed for speed control of asynchronous and synchronous motors, it is primarily intended for ventilation, pumping and process equipment where service continuity, setpoint accuracy and energy management are critical. Power supply is 170-264 V, compatible with single-phase or three-phase 200-240 V, with a protection rating of IP20 and a built-in EMC filter for electromagnetic compliance. Its nominal power is 3 kW for standard use, and 2.2 kW when powered exclusively by single-phase 200-240 V. This technical positioning makes it a relevant choice for HVAC upgrades, reducing mechanical stress at start-up and optimising overall line efficiency.

Technical specifications

• Manufacturer reference : ATV61HU22M3
• Range : Altivar 61
• Manufacturer : SCHNEIDER ELECTRIC
• Type : Variable speed drive for asynchronous and synchronous motors
• Supply voltage : 170-264 V AC, compatible single-phase or three-phase 200-240 V
• Rated power : 3 kW, approx. 4 CV and approx. 4 HP, or 2.2 kW in single-phase 200-240 V, approx. 3 CV and approx. 3 HP
• Output voltage : three-phase to motor, adapted to the supply voltage according to configuration
• Drive control : speed and torque regulation adapted to HVAC and process applications, depending on configuration
• Protection rating : IP20
• EMC compliance : built-in EMC filter

Overview of the Altivar 61 range

The Altivar 61 series is historically dedicated to variable torque applications and continuous regulation processes, notably ventilation, air handling, pumping and fluid circulation. Engineered to reduce mechanical stress on equipment, it supports soft starts, limits inrush currents and improves component lifetime in operation. In connected industrial environments, this range integrates easily with automation architectures driven by PLCs while providing clear, repeatable local configuration interfaces. Note that the lifecycle of this series is coming to an end, with production stopping on 30/06/2016 and service end announced on 01/01/2025, which strengthens the case for responsive sourcing for maintenance or bringing existing installations back into compliance.

• HVAC and pumping : precise control of fans, extractors, centrifugal pumps and circulation loops with stable setpoint regulation.
• Machinery and utilities : light conveying, dosing, mixing and process auxiliaries requiring continuous speed variation.

The ATV61HU22M3 fits this approach by combining appropriate rated power, compact footprint and structured commissioning for reproducible performance in operation.

Industrial applications

This Altivar 61 frequency drive is suitable for many contexts where speed control affects process quality and total energy consumption.

• Air-conditioning and air handling : ventilation, supply, extraction and pressure/flow compensation with setpoints modulated by pressure or flow sensors.
• Water and fluid pumping : network supply, booster sets, process loops with surge reduction via appropriate ramping.
• Light conveying : transport of finished or semi-finished products with fine adjustment of belt speed.
• Water treatment : aeration, recirculation, auxiliary dosing on wastewater treatment lines.
• Food processing and other processes : production auxiliaries, packaging, process air flows.

Integration and communication

Integration of the ATV61HU22M3 is typically achieved via discrete I/O and analogue signals, with options for communication cards depending on configuration. This enables direct connection to PLCs and coherent supervision within existing architectures. Basic control functions, acceleration and deceleration ramps, and motor protections contribute to safe and controlled operation.

Commissioning relies on a clear operator interface and the manufacturer's configuration tools to ensure structured parameterisation, duplication of settings and traceability of changes. Combined with the built-in EMC filter and IP20 rating, the unit is well suited for clean installation inside properly ventilated control cabinets with wiring that follows EMC best practices.

Availability and warranty

The SCHNEIDER ELECTRIC Altivar 61 ATV61HU22M3 is offered as refurbished units and as exchange units, bench-tested and supplied with a 6 to 24 month warranty depending on the service. Standard Exchange Industry provides shipping within 24 to 72 hours to over 120 countries and supports your maintenance teams to identify the exact reference and the most suitable service, including repair when appropriate. Given the production stop on 30/06/2016 and the announced end of service on 01/01/2025, this reference represents a solution to maintain operational readiness for existing installations. Contact our team for a quick assessment of your need, cabinet compatibility and available lead times.
