BA1405 - Drive - CONTROL TECHNIQUES

Control Techniques BA1405 Variable Frequency Drive - UNIDRIVE SP

The reference variable frequency drive BA1405 belongs to the UNIDRIVE SP range from CONTROL TECHNIQUES. Designed for precise control of three-phase motors in industrial environments, it is aimed at maintenance managers, automation engineers and integrators looking for a robust, quick-to-deploy solution for speed regulation. Powered by three-phase 380-480 V and suited to a power range of 3 to 4 kW with a rated current of 8.8 A, this drive covers common needs in conveying, pumping, ventilation and special machinery. Its place within the UNIDRIVE SP series ensures wide compatibility with existing automation architectures while offering straightforward commissioning and stable operation. In retrofit or obsolescence contexts, it is a reliable option to restore production with consistent performance, optimising energy consumption by fine-tuning speed. Designed for the industrial B2B market, it stands out for fast availability, a modular design and easy maintenance to minimise downtime and secure the process.

Technical specifications

• Manufacturer reference : BA1405
• Range : UNIDRIVE SP
• Manufacturer : CONTROL TECHNIQUES
• Category : Variable speed drive, three-phase variable frequency drive
• Supply voltage : three-phase 380-480 V, 50/60 Hz
• Applicable power range : 3 to 4 kW (≈ 4 to 5.4 HP)
• Rated output current : 8.8 A
• Output voltage : variable three-phase, matched to the motor
• Control type : V/Hz and vector control functions available within the UNIDRIVE SP range
• Interface and configuration : operator panel and manufacturer's software tools depending on configuration
• Integration : cabinet mounting, standard connections for industrial three-phase motors

Overview of the UNIDRIVE SP range

The UNIDRIVE SP series is designed to deliver precise speed and torque control across a wide variety of industrial applications. Known for its integration flexibility and modular architecture, it simplifies deployment both in new installations and as a replacement for existing equipment. The range offers, depending on configuration, V/Hz and vector control functions to optimise drive dynamics and process stability. This approach allows fine adjustment of motor speed according to load, resulting in measurable energy savings and better control of cycle times. Thanks to its hardware and software options, UNIDRIVE SP adapts to the needs of production workshops, utilities and packaging lines, while remaining consistent with preventive and corrective maintenance practices.

• General applications : high-efficiency speed control for pumps, fans, conveyors and compressors, with simple and reproducible tuning.
• Dynamic applications : demanding drive control for web tension, axis synchronization and positioning where control accuracy is a priority.

Positioned in this series, the BA1405 model covers the 380-480 V range for a power of 3 to 4 kW with a rated current of 8.8 A. This combination makes it a relevant choice for small to medium power drives where stability, consistent regulation and service continuity are decisive for process quality and equipment availability.

Industrial applications

The BA1405 drive integrates into many environments, from continuous processes to discrete production machines, both for new installations and retrofits. It meets the needs of utilities and production lines that require stable and repeatable control while simplifying diagnostics and maintenance. Typical sectors include handling, processing and site utilities.

• Conveying and handling : speed control of drive motors on belt conveyors, roller conveyors or elevators.
• Pumping and water treatment : control of centrifugal pumps with speed adaptation for flow and pressure.
• Industrial ventilation and HVAC : optimisation of fan and extractor operating points.
• Packaging : synchronization of drive sections and control of web tension.
• Textile and printing : consistent speed control on winders, unwinders and rewinders.
• Food industry : dosing, mixing and transfer, with controlled throughput and soft starts.
• Special machines : assembly machining, semi-automated lines, control of auxiliary axes.

Integration and communication

Integration of the BA1405 into an automation architecture is straightforward via standard I/O and optional modules in the range, enabling connection to programmable logic controllers and CNC systems. Depending on configuration, the UNIDRIVE SP range accepts major industrial fieldbuses via dedicated cards, facilitating the exchange of setpoints and diagnostics at the line level. Configuration can be carried out via a local operator panel and the manufacturer's software tools, with a clear structure for basic parameters, acceleration, braking and motor protections. This approach supports rapid commissioning, reproducible settings and traceability of changes, essential points for maintenance and quality audits.

In contexts requiring finer control, the series offers advanced control functions, typical of a servo-drive when enabled within the range, to improve dynamics and precision. Compatibility with multi-vendor automation environments is strengthened by standardized communication options, contributing to seamless integration into existing installations.

Availability and warranty

The CONTROL TECHNIQUES BA1405 drive is available from Standard Exchange Industry as tested refurbished supply, as a standard exchange unit or repaired depending on the condition of your equipment. Each refurbished unit is bench-tested before shipment and supplied with a warranty in line with our service. Shipping is carried out within 24 to 72 hours to over 120 countries, to reduce equipment downtime. Our technical team can assist you in identifying the correct reference for your motor and network, verify the consistency of essential parameters and advise on best practices for commissioning and preventive maintenance. This approach aims to secure production restart, optimise speed regulation and support the energy performance of your lines in a factual and measurable way.
