CIMR-V7AZ20P1 - Variateur de vitesse - YASKAWA
YASKAWA variable speed drive reference CIMR-V7AZ20P1. VARISPEED V7 range.
Characteristics: 3x200V, 0.1kW, 0.8A.
This YASKAWA drive is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
Drive tested on an engine test bench.
Sensorless vector in pocket size
• Nominal torque at 0.5 Hz
• Autotuning
• High carrier up to 14 khz
• Stop accuracy function.
• Integrated PID controller and bidirectional PID-out put
• Motor protection with PTC input
• Pulse input
• Standard digital operator with copy function
• Fieldbus: Modbus, DeviceNet, PROFIBUS, CANopen
• High speed motion bus: ML- II
• Plug-in PLC option unit. Total inverter access.
• CE, UL, and cUL marked
V7 IP65
• Compact size
• Easy wiring
• Built-in filter (Class B)
Customized software*
• The inverter software can be customized to meet
specific application. Examples:
• Traverse sofware S-9381.
*For detailed information please refer to case software section.
Ratings
• 200 V Class single-phase 0.1 to 4 kW
• 200 V Class three-phase 0.1 to 7.5 kW
• 400 V Class three-phase 0.2 to 7.5 kW
Yaskawa The company was founded in 1915 and its headquarters is located in Kitakyushu, Japan.
The company is the world leading manufacturer of servo motors, converters, axis drives and control systems used in industrial automation, and Motoman robots.
