SK2201 - Variable speed drive - CONTROL TECHNIQUES

Control Techniques SK2201 Variable Frequency Drive - Commander SK

The SK2201 variable frequency drive belongs to the Commander SK series from Control Techniques. Designed to control three-phase induction motors in industrial environments, it meets the needs of maintenance managers, automation engineers and integrators seeking a reliable, compact drive that is quick to commission. The Commander SK series is known for its ease of use and compactness, two major advantages for modernising installations, urgently replacing failed drives and improving energy efficiency in standard applications. The SK2201 provides precise speed variation, controlled acceleration and deceleration ramps, and a smooth start-up that limits mechanical stress. Its design simplifies integration with a programmable logic controller, a numerical controller or an existing automation system, while keeping parameterisation straightforward and easy for maintenance teams to read.

Technical specifications

• Manufacturer reference : SK2201
• Range : Commander SK
• Manufacturer : Control Techniques
• Type : AC variable frequency drive for three-phase induction motors
• Supply voltage : to be confirmed on the nameplate of the SK2201 model
• Rated power : to be verified according to the configuration specified by the manufacturer
• Nominal output current : to be confirmed on the drive's rating plate
• Output voltage and frequency : variable depending on the setpoint and speed configuration
• Control functions : V/f speed control, acceleration and deceleration ramps, controlled stop according to parameters
• Degree of protection : dependent on the installed Commander SK series version
• User interface : local keypad and simplified configuration depending on options available in the series

Overview of the Commander SK range

The Commander SK series groups AC drives intended for general industrial applications, with a focus on easy commissioning, compact cabinet footprint and reliable continuous operation. This range has established itself on lines that require precise speed modulation, progressive start sequences and measurable reductions in energy consumption. The control architecture allows quick adaptation to standard induction motors, and the parameterisation philosophy enables achieving an operational result without heavy software overhead.

• General applications : conveying, pumping, ventilation, assembly machines and auxiliary equipment where the objectives are speed stability, mechanical protection and control of acceleration cycles.
• Simplified integration : clear terminal block, standard motor protection features, basic parameters accessible and mounting options designed for reduced cabinet footprint.

The SK2201 follows this approach, offering a solution for controlling three-phase induction motors with a pragmatic compromise between ease of deployment, regulation stability and simplified maintenance.

Industrial applications

The SK2201 is suited to installations where speed variation directly contributes to service continuity and energy efficiency. It is used to replace existing drives or for new projects requiring reliable control of induction motors. Relevant sectors include logistics, food processing, water and environmental, as well as assembly and packaging.

• Conveying : maintain consistent speeds, simple line synchronisation and reduction of jolts during starts and stops.
• Pumping : adapt speed to demand to reduce consumption, protect piping and stabilise flow rates.
• Ventilation : adjust airflow according to process or comfort setpoints, reducing noise levels and losses.
• Assembly and packaging machines : control auxiliary movements, manage repetitive cycles and reduce mechanical wear.
• Material processing : speed adjustment on rollers, mixers or dosing units when setpoint accuracy and repeatability are required.

Integration and communication

The SK2201 integrates into architectures controlled by a programmable logic controller or a numerical controller, thanks to standard I/O and communication options available within the Commander SK series. Depending on the chosen configuration, it is possible to transmit speed setpoints and operating statuses to the automation system to ensure supervision, controlled stop and first-level diagnostics. Wiring topology and the choice of control signals are determined according to site requirements and applicable standards.

Commissioning is based on an accessible basic parameter set, including motor selection, ramps and protection thresholds. Parameter duplication aids may be available depending on series accessories, facilitating rapid replacement of a drive on a line. This methodology reduces downtime during corrective maintenance and improves consistency of settings across a heterogeneous fleet of drives.

Availability and warranty

The Control Techniques SK2201 is offered by Standard Exchange Industry as supply, exchange or repair. Each supplied or reconditioned unit is bench-tested according to documented internal procedures, then delivered with a commercial warranty ranging from 6 to 24 months depending on the chosen service. SEI ships within 24 to 72 hours to over 120 countries, with dedicated technical support to confirm compatibility with your motor and automation architecture. In the event of a production discontinuation, our team will help you quickly identify the exact reference within the Commander SK series and define the most appropriate solution, whether that is an immediate supply, a standard exchange for rapid restart, or a repair backed by a priced diagnostic. Contact us to schedule the intervention, verify motor parameter matching and secure recommissioning while respecting your process constraints.
