C200-011 00017A

This drive reference C200-011 00017A and brand LEROY SOMER is a drive from the Commander C200 range.

C200-011 00017A: 1 Phase 100/120Vac, 0.25kW, 1.7A.

This LEROY SOMER drive is available to replace your defective equipment and has an appropriate warranty.

Drive tested on an engine test bench.

In stock, ready to ship.
State
  • REPAIR SERVICE
Warranty
€220.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



Commander C

A reference in motor control The new Commander C series builds on the knowledge acquired through the different generations of drives to meet the most stringent requirements of a wide range of applications and offer an optimal user experience.

Simple motor-variator association and performance control

◼ Default fixed boost for easy configuration

– Control of several motors

◼ U/F on advanced performance

– 100% torque available down to 1 Hz

– Slip compensation

– Quadratic U/F mode

– Dynamic U/F control

– Self-calibration (at rest and in rotation)

◼ Open loop vector mode

◼ Improved open loop RFC mode

– Closed current loop for greater stability

– Self-calibration (at rest and in rotation)

Flexible connectivity

The Commander C's SI (System Integration) interface provides integration of a wide range of standard fieldbuses or additional I/O to enable remote control and diagnostics on different networks. The AI-485 Adapter option provides connection to RS485 networks using the Modbus RTU protocol.

Robust and reliable design

◼ Varnished electronic cards to withstand the harshest environments

◼ Patented ventilation system to cool and protect components

◼ Voltage tolerance for smooth operation in the event of supply voltage variation

◼ Interchangeable 3-speed intelligent fan with failure detection function

◼ Fault prevention function to avoid trips:

– Overload management function decreases speed at current limits

– The power failure management function ensures drive operation in the event of a power failure

◼ High overload capability – 180% for 3s (RFC-A mode) or 150% for 60s (open loop mode)

◼ Ingress protection: IP21-UL open class (NEMA 1) Better control and lower costs

◼ Embedded API

◼ Built-in on-board PID control

Energy savings

◼ Dynamic U/F mode - improves efficiency by reducing motor voltage during periods of low demand

◼ Up to 98% efficiency - only 2% energy loss during the conversion process

◼ Low Power Sleep Mode - Drives can be left idle for extended periods of time saving energy

◼ Intelligent 3-speed fan - adapts to engine load and environmental conditions to save energy and reduce noise

◼ Quadratic U/F mode - optimized for quadratic loads, such as pumps and fans to reduce motor losses

Height
13 cm / 5,1 in
Width
7,7 cm / 2,9 in
Length
16 cm / 6,2 in
Weight
0,8 kg / 1,7 lb
Family
Commander C200
Reference
C200-011 00017A
Refurbished
3000110789502
300110789506

LEROY SOMER, leader and global specialist in industrial alternators and drive systems, designs and industrializes the most innovative eco-technology solutions to serve the industrial and tertiary markets.

Founded in 1919 by Marcellin Leroy

International company headquartered in Angoulême in Charente (France), worldwide specialist in alternators and electromechanical and electronic drive systems. Subsidiary of the American group Emerson since 1990.

In 2017, Nidec Cormoration took effective control of Leroy Somer.
