25B-A8P0N104 - Variable speed drive - ALLEN BRADLEY
This reference speed controller 25B-A8P0N104 and brand ALLEN BRADLEY is a drive from the POWERFLEX 520 series. POWERFLEX 525.
Variable speed drive: 200...240V AC - single phase input, three-phase output 0...230V / 2.0CV, 1.5kW
This ALLEN BRADLEY speed controller is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
System overview
The PowerFlex® 520-Series AC drive is based on an innovative new concept that is particularly versatile and can be adapted to systems that range from stand-alone machines to integration into a single system.
The PowerFlex 523 drive provides general purpose control for applications up to 15 HP and 11 kW. The variatorPowerFlex 525 offers maximum flexibility and performance up to 30 HP and 22 kW.By combining a variety of motor control options, communication, energy saving and standard safety features in one value-for-money drive, the PowerFlex 520 Series is suitable for a wide range of applications.Optimize your system performance and improve your productivity by enjoying the benefits of featuresessentials offered by the PowerFlex 520-Series drive.
PowerFlex 520-Series AC Drives Specifications
Modular design
• Removable control module and power module allowing configuration and installation to be carried out simultaneously.
• Each drive has a standard control module used over the entire power range.
• MainsFree ™ setup allows you to simply plug your control module into a PC using a standard USB cable and upload, download and flash new drive settings.
• Support for accessory cards without impacting the footprint. (PowerFlex 523 drives support one, PowerFlex 525 drives two)
Packaging and assembly
• Installation can be quick and easy with DIN rail mounting size A, B and C drives. Panel mounting is also available for flexibility.
• Side-by-side Zero Stacking ™ mounting is permitted for ambient temperatures up to 45 ° C, which reduces
considerably congestion.
• An integrated filtering system is available for all 200V and 400V ratings, providing a cost effective device that meets the EMC requirements of EN61800-3 Category C2 and C3. External filters meet the EMC requirements of EN61800-3, Category C1, C2, and C3 for all ratings of PowerFlex 520-Series drives.
• An optional IP 30, NEMA / UL Type 1 junction box easily adapts to the standard IP 20 (NEMA Type Open) product for higher environmental classification.
Performance optimization
• Removable grounding varistors for safe operation when used on ungrounded distribution systems.
• A precharge relay limits the inrush current.
• Internal braking transistor, available on all nominal capacities offering a braking function
dynamic with simple and low-cost braking resistors.
• A jumper allowing switching between an NPN or PNP 24 VDC control increases the flexibility of the
control wiring.
• Double overload regime available for drives with power greater than 15 HP / 11 kW. Normal duty: 110% overload for 60 seconds or 150% for 3 seconds. Heavy Duty: 150% overload for 60 seconds or 180% overload (200% programmable) for 3 seconds for robust overload protection.
• Adjustable PWM frequency up to 16 kHz to ensure quiet operation.
PowerFlex 520-Series AC Drive Advanced Features
Command performance
• Large selection of engine control options including:
• Volts per hertz (V / Hz)
• Vector control without encoder (SVC)
• Closed loop speed vector control (PowerFlex 525 drives only)
• Large selection of positioning controls, including:
• PointStop ™ stops the motor load in a defined position without encoder feedback
• Closed loop feedback signal with optional encoder card (PowerFlex 525 drives only)
• Point-to-point positioning mode (PowerFlex 525 drives only)
• Built-in PID functionality improves application flexibility (PowerFlex 523 drives have one PID loop, PowerFlex 525 drives have two)
