MDV60A0370-503-4-00

This SEW drive reference MDV60A0370-503-4-00 is part of the MOVIDRIVE MD 60A range.

Input: 3x380 ... 500V, 50 / 60Hz, 65.7A, Output: 51.1kVA, 73A, 37kW.

This SEW inverter drive is at your disposal to replace your defective equipment and has a suitable guarantee.

Drive tested on motor test bench.

In stock, ready to ship.
State
  • Refurbished Supply
Warranty
€2,520.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



MCF: Vector control without encoder for asynchronous motor.

VCF modes only (VCF = Voltage Flux Control)

MDV: Vector control without and with encoder for asynchronous motor.

VFC and CFC modes (CFC = Current Flux Control)

MDS: Vector control with resolver for synchronous motor

Servo Modes

MDR: Network reinjection module

System Description

A large number of movements have to be controlled in automated conveyor and logisticsapplications in order to transport the material. Linear movements in the form of trolleys and hoists, and rotary movements with rotary tables, play an important part in these applications.Rotary movements often occur in pulses (rotary indexing tables) in which the material is moved onby a certain number of degrees every cycle. However, there are also many rotational applications inwhich the material should be moved to its destination by the shortest possible route (distance-optimized positioning) or in which it is only permitted to move to the target position in a defined direction of rotation (positioning with fixed direction of rotation).The position axis is represented on a numbered circle from 0 to 360° in order to meet theserequirements. As a result, the actual position always moves within this range.The round axle application model accomplishes these tasks with various operating modes whichare selected using the binary inputs or the virtual terminals (control via fieldbus).

Application fields :

- The round axle is particularly suited to the following applications :

Lathes

Rotary tables

Rotary indexing tables

Swiveling devices

Feed units

Timing belts

The round axle offers the following advantages in these applications :

• User-friendly user interface

• You only have to enter the parameters required for the round axle (ratios, speeds, diameters)

• User-friendly application programs guide you through the process of setting parameters, sothere is no need for complicated programming

• Monitor mode for optimum diagnosis

• You do not need any programming experience

• It doesn't take long to get to know the system

Height
35 cm / 13,7 in
Width
28 cm / 11 in
Length
53 cm / 20.86 in
Weight
27 kg / 59,52 lbs
Family
MOVIDIVE MD 60A
Reference
MDV60A0370-503-4-00
