C3S038V4

This PARKER servo drive reference C3S038V4 is part of the COMPAX3 series.

C3S038V4: 3 phases 400/480V, 3.8A, 3.1kVA.

This PARKER drive is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.

In stock, ready to ship.
State
  • Refurbished Supply
Warranty
€390.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



The new range of Compax3 servo drives covers all servo control needs. Modular, it offers the guarantee of always having a hardware and software configuration adapted to the requirements of the application, from the simplest to the most complex. Taking into account standards relating to communication and programming reduces the need to acquire specific knowledge. Any type of servomotor can be driven: classic brushless motor, linear motor or torque motor….

TECHNICAL SPECIFICATIONS

Power supply: 230VAC/240VAC, 80-253VAC/50-60Hz, single or three-phase 400VAC/480VAC, 80-528VAC / 50-60Hz three-phase



Regulations:

Current loop: 62.5μs Velocity and position loop: 125μs

Motion control (T11/T30/T40):

500μs setpoint generator

Synchronization via HEDA real-time bus (up to 18 axes)

Register marks: detection accuracy < 1μs Electronic gear

Virtual Master (T40)

Electronic cams 10000 points (T40)



Programming IEC61131-3 (T30-T40):

IEC61131-3 programming environment

CodeSys

PLCopen function blocks

Multi-axis control (PowerPlmC)

Programmable automaton with motion functions

IEC61131-3 programming via Ethernet interface

Available in integrated or standalone version

Supported engines:

Synchronous motors (max speed for 10 poles: 12000 rpm)

Linear motors, Hall effect sensor

Supported sensor type:

Resolver, SinCos encoder, Hiperface, EnDat, Linear encoder

Inputs and outputs:

8 control inputs: 24V DC / 10kohms.

4 control outputs: 24V / 100mA.

2 analog inputs (+/-10V, 14 bits)

2 analog outputs (+/-10V, 8 bits)

RS232/RS485 serial communication port

Optional expansion of digital I/O

Fieldbus:

Profibus-DP V0-V2 (I20)

CANopen (CiADS402) (I21)

DeviceNet (I22)

Ethernet Powerlink (I30)



“Safe Stop” safety input according to EN954-1* (category 3)

Height
17,2 cm / 6,62 in
Width
10cm / 3.94in
Length
28 cm / 11 in
Weight
3,5 kg / 7,7 lbs
Family
COMPAX3
Reference
C3S038V4

Founded in 1918, the Parker Appliance Company has evolved into Parker Hannifin Corporation, reflecting a legacy of innovation. We believe that our future development is assured if we respect Parker's tradition of excellence.
