FR-E740-0.75K - Frequency inverter - MITSUBISHI
This MITSUBISHI drive, reference FR-E740-0.75K is a frequency drive. It belongs to the FREQROL-E700 range.
Mitsubishi dimmer: 3x380-480V, 2.6A, 0.75kW.
This MITSUBISHI drive is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
Very Simple
■ Easy to Operate
● We added a frequency setting knob (run by a varistor) to the control panel as standard. Variable speed operation is availabl soon after power is turned on. The control panel is removable, so you can install it on a main control panel with optional nequipment and “off-the-shelf” cables. The knob itself is removable. You can also operate it remotely using parameter settings and externally input frequency setting signals.
■ The Parameter Unit
● The FR-PU04 is another option available. It takes direct input from a key pad. It uses a long-life backlit LCD and allows you to copy parameters. Eight languages are available ( Japanese, English, German, French, Spanish, Italian, Swedish, and Finnish). Connect it with the separately sold cable.
● We've made parameter user group functions as standard. You can select just the parameters you need for writing and reading to simplify parameter management.
● You can use the setup software for parameter settings. We've provided optional software that lets you use a personal computer to assist you in everything from starting up the inverter to maintenance
■ Easy to Maintain
● Easy access makes changing the cooling fan very simple. Operating life can also be increased by turning ON-OFF control on.
■ Easy to Wire
● A screwed terminal plate is used for the main circuit.
● A screwed terminal plate is also used for the all new control circuit (with plug in leads). The wide lead holes allow two leads to be plugged in simultaneously.
Very Compact
■ Most Compact Inverter in its Class
Only 85% the volume of a Mitsubishi FREQROL-U100 (for FR-E520- 0.2K).
■ Height is Now Standardized
All models from 0.1 to 3.7kW are the same 128mm in height. This makes panel layout easier. (Except FR-E540)
