SJ700-075 HFEF2

This HITACHI brand SJ700-075 HFEF2 variable frequency drive is a drive from the SJ700 range.

Variable frequency drive: Input: three-phase 400V, 23A; Output: 7.5kW, 19A.

This HITACHI drive is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.

In stock, ready to ship.
State
  • New Supply
Warranty
€2,520.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



High performance, powerful functions, user friendly.

A powerful drive with high starting torque and easy configuration

Improved Sensorless Vector Control and Auto Tuning allow for the easy setup of motor constants and enable a high starting torque of 150% or more at 0.5Hz. The SJ700 inverter is a general purpose inverter which can also be applied to high torque applications

Trip avoidance functions

Over current suppression

Higher internal calculation speed improves Current control performance.Over-current suppression helps to avoid an inverter trip during acceleration, deceleration and impact loads.

Over voltage suppression

Using the DC bus AVR Function the deceleration time is controlled in order to avoid exceeding the over-voltage trip level. This enables trip-less operation.

EMC Filter & Brake Circuit integrated as standard

Built-in EMC Filter

Cost and space can be reduced when compared to use of an external EMC Filter.

Brake Circuit up to 30kW

Cost and Space reduction compared with external Braking Controller.

Easy Maintenance

Easy-removable components

Cooling fan(s) and DC bus capacitors can be easily removed for cleaning or replacement.

The removable Logic terminal block of SJ300/L300P are compatible with SJ700. Re-wiring is not necessary

Network compatibility

Various Fieldbus options available

The SJ700 inverters are fitted with a serial RS-485  Modbus-RTU port as standard. The inverters can be  connected to the following fieldbus networks, using  separately available option boards:

■ PROFIBUS-DB

■ CanOPEN

■ DeviceNet

■ and other networks

Easy Operation

User defined display parameters

The user can select from a number of parameter display  modes.

• Data comparison function  Displays only those parameters, which have been changed from the  default.

• User selected function Displays up to 12 user defined parameters (U001-U012)

• Basic mode (default)  Displays commonly used parameters

Long Life time

Life time warning function

Through monitoring of the lifetime warning and other functions, preemptive component maintenance can be carried out to avoid unexpected system failures.

Long life time components

The advanced design of the cooling fan(s) and the DC bus capacitors results in a calculated life time of 10 years*. The ON/OFF control function can extend the life time of the fan(s) even further. *Ambient temperature: SJ700B: 30° C (no corrosive gases, oil mist or dust

Height
17 cm / 6,6 in
Width
21 cm / 8,2 in
Length
26 cm / 10,2 in
Weight
6 kg / 13,2 lbs
Family
SJ700
Reference
SJ700-075 HFEF2
