MAS51A010-503-00 - Servo controller - SEW

Servo controllers of the MOVIDYN unit series are microprocessor-controlled pulse inverters that control speed ant torque of permanent-field DFS/DFY synchronous motors. They can be powered with a supply voltage of 380...500 Vac with 50/60 Hz and deliver output currents of 5 to 60 Aac. In addition to the amplifier system with power supply modules to wich axis modules (maximum 6) can be connected, a compact servo controller that combiens the functions of the power supply and axis modules is available for smaller currents (5 to 15 A).

All electronic inputs and outputs are potiential-free to the power supply voltage since the complete electronics is supllied by a separate power supply.
This also makes it possible to supply the units by feeding 24 Vdc externally and set the paramaters without using the supply voltage.

MAS axis Modules : The axis modules are connected with the DC link and the protective conductor via bus bars. A separate 24 Vdc bus is used for the voltage supply of the contorl electronics. A data bus is installed at the bottom sides of the units for interconnected communication of the units.

MKS Compact servo controller : The compact servo controller combines the functions of the power supply module and axis module of the modular servo controller
