6SL3120-2TE21-0AA0 - Double Motor Module - SIEMENS
This double motor module 6SL3120-2TE21-0AA0 and brand SIEMENS is a 2x9A drive. This drive belongs to the SINAMICS S120 range.
SINAMICS S120 double motor modules: 600V DC output: 3AC 400V, 9A / 9A internal air cooling INCL. DRIVE-CLIQ CABLE
This Siemens 6SL3120-2TE21-0AA0 drive is at your disposal to replace your defective equipment and has a warranty.
Double Motor Modules feature the following interfaces as standard:
• 2 DC link connections via integrated DC link busbars
• 2 electronics power supply connections via integrated 24 V DC bars
• 4 DRIVE-CLiQ sockets
• 2 plug-in motor connections (not included in scope of supply)
• 2 safe standstill inputs (1 input per axis)
• 2 safe motor brake control
• 2 temperature sensor inputs (KTY84-130 or PTC)
• 3 PE (protective earth) connections
The status of the Motor Modules is indicated via two multi-color
LEDs.
On Double Motor Modules, the motor cable shield can be connected in the connector.
The signal cable shield can be connected to the Motor Module by means of a shield connection terminal, e.g. type KLBÜ 3-8 SC by Weidmüller.
The scope of supply of the Motor Modules includes:
• DRIVE-CLiQ cable (length depends on module width) to connect Motor Module to adjacent module
• Jumper for connecting the 24 V DC busbar to the adjacent Motor Module
• Connectors X21 and X22
