3G3MX2-A2055-E - Servodrive - OMRON
Ideal for controlling your machines
• Current flow vector control
• High starting torque: 200% at 0.5 Hz
• Double power regime VT 120% / 1 min and CT 150% / 1 min
• Asynchronous (IM) and synchronous (PM) motor control
• Torque vector control in open loop
• Positioning functionality
• Integrated application functionalities (eg: braking control)
• Built-in logic programming
• Fail-safe according to ISO13849-1 (dual input circuit and EDM external device monitoring)
• USB port for computer programming
• 24 VDC backup power supply. for the control board
• Fieldbus communications: Modbus, DeviceNet, Profibus, CompoNet, EtherCAT, ML-II and EtherNet/IP
• PC configuration software: CX-Drive
• RoHS, CE, cULus
Powers
• 200 V single-phase models from 0.1 to 2.2 kW
• 200 V three-phase models from 0.1 to 15.0 kW
• 400 V three-phase models from 0.4 to 15.0 kW
Indoor security
• Meets Cat ISO-13849-1 3 performance safety standard
• 2 security level D inputs
• External device monitoring (EDM)
Logic programming
• Programming flowcharts
• Intuitive - up to 5 tasks in parallel
Positioning
• Up to 8 preset positions with "Homing"
• Speed synchronization
Integrated into Omron intelligent automation
• CX-Drive programming tool connected via the integrated USB port on 3G3MX2.
• Modbus RS485
• Optional integrated units for EtherCAT, Profibus, DeviceNet, ML-II, EtheNet/IP and more…
Omron was created by Kazuma Tateish in 1933. Based in Kyoto, Japan, Omron Corporation is a global leader in automation. Headed by President Yoshihito Yamada, Omron has approximately 37,000 employees in more than 36 countries who offer products and services in various areas, including automation components and systems, electronic components and medical and paramedical products.
