DKR02.1-W300

This INDRAMAT reference DKR02.1-W300 drive is a system from the DKR range.

Features: 3x400/480Vac, 50/60Hz, 212A.

This INDRAMAT drive is at your disposal to replace your defective equipment and has an appropriate guarantee.

Drive tested on an engine test bench.

In stock, ready to ship.
State
  • Refurbished Service Exchange
  • Refurbished Supply
Warranty
€1,800.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



Drive controllers of the DKR type have been designed for digital intelligent control of the following Rexroth Indramat motors:
• a.c. main spindle motors 2AD or ADF,
• frameless spindle motors 1MB and
• linear motors LSF or LAF.
The output of these motors is between 10 and 93 kW of continuous power at the motor output shaft.
For precise control and regulation of the motors there are DKR drive controllers with different power ratings available.
Drives equipped with the DKR drive controller feature
• a high level of control and
• a broad speed range with constant power.
They are, for example, especially well-suited for use in
• NC-controlled machine tools or
• printing machines.

DKR drive controllers have been designed for direct mains connection to grounded AC mains with 3xAC 400 V ... 480 V.
They are equipped with an integrated mains contactor and an emergency stop shutdown device.
Regenerated braking energy is supplied to the mains again – also in case of emergency stop.
DKR02 and DKR03 devices can be ordered with an integrated brake resistor, the DKR04 device can be expanded by an external brake resistor. This allows decelerating a drive even if the mains fails.

Heatsink and blower are already integrated into the housing. The cooling air is conducted through the machine in an air duct. This type of construction means that whichever cooling variant is selected, it can be quickly adapted to all demands and requirements, as, for example,
• with air from inside the control enclosure,
• with air from outside the control enclosure or
• cooling with a duct.

Various components, i.e., modules, are available for insertion into the basic unit of the DKR. It is by means of these components that the DKR can be adapted to a specific application, e.g., an already mounted measuring encoder.
The basic unit is adapted to your application by fitting individual plug-in cards into slots U1 through U5. Rexroth Indramat delivers the unit completely configured. A configured drive consists of:
• the basic unit,
• a software module,
• command interface card(s) and
• auxiliary plug-in module(s).
Three name plates are mounted to make sure that the configured drive is clearly labeled.
A configured DKR must be ordered with the required firmware, i.e., FWA-DIAX03-.... . Each firmware version is a subitem and must be ordered separately.
The firmware is the operating software of the DKR which is installed in the form of EPROMs on the DSM software modules and, if necessary, on an auxiliary plug-in module.

Auxiliary plug-in modules with the following features are currently available:
• modules with digital I/Os for bidirectional data exchange,
• modules for different types of measuring systems:
• incremental measuring systems with square-wave signal output
• incremental measuring systems with sinusoidal signal output
• singleturn encoder measuring systems
• multiturn absolute encoders with SSI signal output
• Rexroth Indramat toothed wheel encoders
• measuring systems with analog power signals
• analog signal interface,
• modules with CLC link interface

Height
35 cm / 13,7 in
Width
44 cm / 17.3 in
Length
100 cm / 47,2 in
Weight
100 kg / 220 lbs
Family
DKR - INDRAMAT
Reference
DKR02.1-W300
Refurbished
3000092931890
300092931894

Indramat is an industrial company founded in 1958, based in Neuwied, Germany.
Indramat Gmbh , which is now part of Bosch Rexroth , was an industrial control company founded in 1958, based in Neuwied (am Rhein), Germany. Its name is a German abbreviation meaning «Gesellschaft zur IND ustrialisierung- RA tionalisierung und Auto MAT isierung».
