U-DS 020.1

This reference U-DS 020.1 servo motor drive and LUST brand is a drive from the U-DS DriveStar series.

U-DS 020.1: 3x230V, 11kW, 20A.

This LUST servo drive is at your disposal to replace your defective equipment and has an appropriate guarantee.

Drive tested on an engine test bench.

In stock, ready to ship.
State
  • Refurbished Supply
Warranty
€1,950.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



DriveStar series servo converters are used for continuous low-loss speed and torque control.

DriveStar servo converters are intended for the operation of:

• Synchronous motors manufactured by LUST DriveTronics GmbH.

• asynchronous motors with real speed from LUST DriveTronics GmbH.

• asynchronous motors without actual speed by LUST DriveTronics GmbH. Other motors may only be used with the clear permission of LUST DriveTronics GmbH. Follow engine maintenance instructions. The DriveStar servo converter must only be used under the prescribed service conditions. The specified assembly, dismantling, commissioning and maintenance instructions must also be observed.

DriveStar servo converters are fully digitized. They have been designed to drive synchronous and asynchronous motors.

The output currents are sinusoidal and are controlled in pulse width modulation. The switching frequency is at 2-14kHz. The servo converter works digitally with a regulation processor in a VeCon chip having a cycle time of less than 62 µs. Communication and operation are controlled by a 16-bit processor, which is integrated into the VeCon chip. Together, the two processors form an ASIC (Application Specific Integrated Circuit), enabling optimal regulation characteristics, maximum dynamics and simple menu-guided operation. The strict division of tasks of the microprocessors enables the linking of complex technological regulations and customer-specific software. That's to say. same equipment with different regulatory and technological obligations. DriveStar units are suitable for:

• Regulation for synchronous drives

• Regulation for asynchronous motors with detection of current vectors by a calculated flux (field-oriented regulation for asynchronous motors).

In both cases, the high regulation expenses result in three-phase drives requiring less maintenance having the behavior of d.c. discs.

• Control for standard asynchronous motors as frequency converters and speed converters.

Height
36 cm / 14,1 in
Width
8,5 cm / 3,3 in
Length
26 cm / 10,2 in
Weight
6,8 kg / 14,99 lb
Family
U-DS
Reference
U-DS 020.1

LTi is a key player in servo technology, in addition to being established in sectors such as renewable energy, microsystems, sensor technology and electronics.

With nearly 1000 employees worldwide, the LTi group of companies develops and produces a wide range of innovative products.
