S62000 - Digital Drive - KOLLMORGEN
This digital drive reference S62000 and brand KOLLMORGEN is a drive from the SERVOSTAR S600 range.
S62000: 3x230-480V, 14kVA, 20A
This KOLLMORGEN drive is at your disposal to replace your defective equipment and has an appropriate guarantee.
SERVOSTAR® 600
Equipped with a multi-network power supply and a connection for all types of voltage, the SERVOSTAR® 600 generation innovates in the concept of the digital drive. Great flexibility of hardware and software, easy connections and settings, multitasking and multifunction offered as standard are the arguments of this device. Innovative technology combined with an attractive design allow you to solve almost any training need. With our synchronous servomotors, important accessories, pre-assembled cables, gearboxes, power supply units, etc., you will find a complete solution for your digital drive needs with us.
highlights
• Direct three-phase network, 230V-10% ... 480V+10%, 50 Hz 208V-10% ... 480V+10%, 60 Hz
• Integrated filters up to 20 A
• All shield connections directly on the amplifier
• Intermediate circuits in parallel connection, with patented ballast distribution possible
• Choice of encoder emulation, compatible with ROD426 (dec./bin.) or SSI (gray/binary)
• Feedback by resolver (standard) or by high resolution sine-cosine encoder
• Fully programmable via RS232 interface
• Control via PC running under WINDOWS™ 95/98/2000/ME/NT/XP
• Parameterization by 2 keys, directly on the amplifier
• Integration up to 20A in a 300 mm box
• Step-by-step interface, master slave application, gearbox with integrated CANopen ratios integrated
• Intelligent positioning: Speed profile, position information by cam, jerk limitation, linking of positions, absolute or relative movement, different types of referencing
• Slot for an expansion card: PROFIBUS DP, SERCOS, DeviceNet, Ethernet, Single Axis Controller or I/O-Extension
WINDOWS™ Setup Software
The WINDOWS™ 95/98/ NT/ 2000/ME/XP compatible operator software offers direct access to all important parameters of the SERVOSTAR® 600. During commissioning, setting parameters can be optimized online – with the dimmer in operation. The window technique allows the simultaneous representation of several interconnected servo amplifiers via the basic CANopen bus. Integrated oscilloscope function, Bode plot, the ASCII code is readable through our program, engine data and engine settings integrated into our systems allowing easy start-up and accessible to all.
With over 100 years of design and development expertise, Kollmorgen delivers breakthrough motion solutions unmatched in performance, reliability and ease-of-use. Through world-class knowledge in industrial automation, leading quality, and deep know-how in linking and integrating standard and custom products, Kollmorgen provides OEMs with the competitive advantage they need to succeed.
