DSD16032

This reference servoamplifier DSD16032 and PARKER is a servo drive from the DIGIVEX DRIVE series.

DSD16032: 400V three-phase 50/60Hz,  32A/64A, 12000W

This PARKER digital servoamplifier is at your disposal to replace your defective equipment and has a suitable guarantee.

In stock, ready to ship.
State
  • REPAIR SERVICE
Warranty
€550.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



DESCRIPTION

The Digivex family of servo drives is available in two product ranges: the Digivex Drive range, intended for the torque/speed control of brushless motors, and the Digivex Motion range, a complete positioning solution integrating a movement program and on-board PLC. Both ranges offer single and multi-axis versions.

Modularity

Direct power supply 230VAC and 400VAC

Single and multi-axis versions

Integrated braking or network forwarding

Motion Program and Embedded PLC (Motion Series)

Fieldbus (Motion Series)

TECHNICAL SPECIFICATIONS

Food :

230Vac ±10%, single or three phase, 400Vac ±10%, three phase; 50/60Hz

Working :

0-40°C (beyond useful power derating of 20% per 10°C increment - max. 60°C). Altitude 1000m (beyond useful power derating of 1% per 100m - max 4000m)

Inputs/Outputs - Drive Series:

2- Analog inputs (16 bits and 10 bits; ±10V diff.)

2- Analog outputs (±10V), configurable

4- Optocoupled logic inputs

3- Optocoupled logic outputs

Solver input

Incremental encoder emulation output; SSI; SinCos

230Vac or 400Vac auxiliary input

Motion Series Inputs/Outputs:

1- Analog input (14 bits; ±10V diff.)

1- Analog output (±10V), configurable

16- Optocoupled logic inputs (including 4 interrupts), configurable

8- Optocoupled logic outputs, configurable

Solver input

Posivex® absolute encoder input

Incremental encoder input; SinCos

Incremental encoder emulation output

230Vac or 400Vac auxiliary input

Fieldbus (Motion Series):

CANopen (DS 301 and DSP 402)

PROFIBUS (DP-V0 and DP-V1; PROFIdrive V2.0 and

PROFIdrive V3.0 Class 3 and 4)

Height
22.6 cm / 8.9 in
Width
17 cm / 6,6 in
Length
33 cm / 12,9 in
Weight
8.8 kg / 19.4 lbs
Family
DIGIVEX DRIVE
Reference
DSD16032
Refurbished
3000236342841
300236342845
