A06B-6058-H003
This FANUC Servo Amplifier series 6058 and reference A06B-6058-H003 is designed to control FANUC motors of type 2-0S, 1-0S.
This 1 axis drive is complete; it includes the reference control board A20B-1003-0030.
This A06B-6058-H003 drive is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.

In stock, ready to ship.
State
  • Refurbished Supply
Warranty
€500.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



The digital AC servo consists of the following.

The position command data from the NC machining program, for example, is processed by the NC controller, which turns it into position command data for each axis. The position command data of each axis is transmitted to a high-performance microprocessor mounted within the NC controller.

In this microprocessor, the position, velocity and current are all controlled on the basis of this data, and it outputs a PWM control signal.

The PWM control signal is fed to a separate servo amplifier, which amplifies this PWM control signal to the required power level for the AC servo motor.

The motor driving current from the servo amplifier, and the motor position data and velocity data passes from the pulse coder, are both fed back to the NC controller.

Make correct connections between a servo amplifier and motor used. If a wrong combination of an amplifier and motor is used, a malfunction such as motor vibration can occur, thus causing a failure.

During parameter setting, an alarm may request that the power be turned off, however, continue setting without turning off power until all parameters are set.
When setting the parameters, keep the system in the emergency stop state. In the excitation state, setting values on the menu can be updated, but the internal data cannot be updated; the parameters are not actually updated.


Before setting a closed loop system (using a separate position detector), the user should check the operation of the machine in a semi-closed loop system (using the pulse coder on the motor).

SEI

Established in France since 2015, STANDARD EXCHANGE INDUSTRY specializes in exchange service, supply and repair of industrial electronic systems.

We offer economic, technical and ecological solutions that are part of a sustainable development strategy. Thus, we often recommend the exchange and repair of the electronic systems which are entrusted to us.

Formed by professional, experienced and dynamic teams, SEI makes every effort to find solutions to your breakdowns. With significant technical resources and twenty years of experience, SEI provides you with a wide range of choices and references for new or reconditioned products, tested on a manufacturer's bench and quickly deliverable.

We work on brands such as SIEMENS, SCHNEIDER, FANUC, OMRON, YASKAWA, MITSUBISHI, LEROY SOMER, on behalf of manufacturers around the world. PLCs, drives, electronic cards, digital controls, panels, consoles, regulators ... all categories of electronic systems are available.

SEI is able to export to over 120 countries by maintaining a large stock of systems ; 3 storage centres in Europe, 1 in the United States and 2 in Asia. This allows us to effectively respond to your urgent needs, particularly those for industrial groups with several production, assembly and / or finishing sites.

Our know-how allows us to work with all industry types : food, automobiles, aeronautics, fenders, railways, pharmaceuticals ...

Height
19 cm / 7,4 in
Width
16 cm / 6,2 in
Length
45 cm / 17,7 in
Weight
5,5 kg / 11 lbs
Family
FANUC SERIE S
Reference
A06B-6058-H003
Refurbished
3005371852163
300813519905

FANUC is a Japanese manufacturer of industrial robots, machining centers and numerical controls for machine tools

Since its creation in 1956, when the company’s founder, Dr. Seiuemon Inaba, introduced the concept of digital controls, FANUC has always been at the forefront of manufacturing techniques in the world. Moving from the automation of a single machine in the late 1950s to the automation of entire production lines over the following decades.
